hwahao/CoreOfPotato: lightweight self-hosted alternative for tinkerers

Core of Potato v1.0.1 is an open-source, lightweight API gateway and browser automation framework designed to run local web-based AI models in parallel browser slots. It bridges the gap between structured API requests (e.g., OpenAI-compatible clients, LangChain, or simple HTTP requests) and free browser-based AI platforms (Grok, Gemini, ChatGPT) using advanced session multiplexing.

🚀 Features

OpenAI-Compatible Endpoint: Seamless integration with tools like OpenAI's official SDKs, LangChain, and other API wrappers at /v1/chat/completions.
Dynamic Headless Toggle: Toggle between headed (visible tabs) and headless (completely silent background processes) on the fly via the Control Panel or REST API. (Note: Running in headless mode is currently only reliably supported on Gemini. Grok and ChatGPT employ strict anti-bot protections that often block headless execution.)
Session Continuity (NaModu Keys): Isolated browser tabs mapped to custom 6-character keys (NaModu format, e.g., OCtest), preserving cookie sessions, conversations, and custom settings.
Human-like Automation: Features human-like typing delays (30-120ms) and intelligent copy-pasting for larger prompts (>500 chars) to prevent bot detection.
Unified Control Panel (Hub): Beautiful dark-themed dashboard served locally at /hub to monitor worker slot statuses (Idle, Busy, Offline), adjust active worker configurations, and inspect real-time system logs.

📐 Architecture

┌───────────────────────────────────────────────────────┐
│  Clients (OpenAI Python SDK, LangChain, cURL, etc.)  │
└──────────────┬────────────────────────────────────────┘
               │ HTTP (port 2809)
               ▼
┌───────────────────────────────────────────────────────┐
│  Core of Potato Server (aiohttp)                      │
│  ├─ /v1/chat/completions (OpenAI Compatible API)      │
│  ├─ /api/* (Management, Logs, Slots, Visibility)      │
│  └─ /hub   (Static Control Panel UI)                  │
│                                                       │
│  BrowserManager (core/browser_mgr.py)                 │
│  ├─ Launches persistent Chromium contexts             │
│  ├─ Maintains separate page slots per platform        │
│  └─ Handles headed/headless toggling                  │
└─��────────────┬────────────────────────────────────────┘
               │ Playwright CDP
               ▼
┌───────────────────────────────────────────────────────┐
│  Stealth Browser (Chromium / CloakBrowser)            │
│  ├─ [Headed]   Visible windows & tabs for debugging   │
│  └─ [Headless] Background execution with low overhead │
└───────────────────────────────────────────────────────┘

🛠️ Setup & Installation

Prerequisites

Python 3.9+
Linux (Debian/Ubuntu/Fedora/etc.), macOS, or Windows

1. Run Setup Script

Run the automated installation script to install Python dependencies and Playwright Chromium drivers, and copy the default config template:

chmod +x setup.sh
./setup.sh

(Alternatively, manually run pip install -r requirements.txt -r requirements-dev.txt, followed by playwright install chromium)

2. Configure Core of Potato

Copy config.example.json to config.json and adjust configurations:

cp config.example.json config.json

Key configuration options in config.json:

host: The host address to bind the server to (default: "127.0.0.1").
port: The port the gateway will bind to (default: 2809).
log_level: Severity level for system console logs (default: "INFO").
job_accept_timeout: Maximum time in seconds to wait for a worker slot to become available before rejecting a job (default: 10).
job_result_timeout: Maximum time in seconds to wait for the automation script to complete a single prompt (default: 180).
log_retention_days: Number of days to retain daily logs in data/logs/ before automatic cleanup (default: 3).
url_default_mode: Default caching strategy for session URLs ("usage_based", "time_based", or "fixed").
url_default_max_uses: Number of times a cached URL can be used under usage-based caching before getting discarded (default: 10).
url_default_ttl_minutes: Time in minutes a cached URL is valid under time-based caching before getting discarded (default: 30).
default_urls: Starting landing page URLs for each automated browser platform.
workers: Configure how many parallel slots are opened for each platform (e.g., "grok": 3, "gemini": 1, "chatgpt": 2).
browser.show_browser_window: Set to true to run browsers in headed mode (visible windows) for debugging, or false to run silently in headless mode (default: true). Note: Headless mode triggers bot protections on Grok and ChatGPT, causing them to fail or timeout. It is recommended to keep this true unless you are exclusively using Gemini.
browser.user_data_dir: Directory where persistent browser login sessions, cookies, and local storage states are saved ("./data/browser_profiles").
browser.viewport: Resolution dimensions for the virtual browser instances.
security.admin_token: Secret authorization token for accessing administrative REST API endpoints (default: "admin-token-change-me").
security.require_auth: Set to true to restrict access to the /v1/chat/completions API endpoint, requiring a valid caller mapping.

3. Initialize Caller Mapping

The system uses 2-character caller prefixes to validate and identify clients (e.g. OC for OpenClaw). While config.json contains a default seed configuration, the active caller mapping is stored and maintained dynamically in data/caller_map.json. At startup, this file is loaded, and any additions/removals made through the Control Panel Hub UI are written directly to it.

Default content of data/caller_map.json:

{
  "OC": "OpenClaw",
  "CD": "OpenCode"
}

🏃 Running the Server

Start Core of Potato with:

python3 -m core

Once running:

API Gateway: http://localhost:2809/v1/chat/completions
Control Panel Hub: Open http://localhost:2809/hub in your browser.

🖥️ Control Panel Hub (Local Dashboard)

Core of Potato serves a premium, dark-themed control panel locally at http://localhost:2809/hub (and automatically launches it in a Playwright tab at start). It provides real-time telemetry, configuration tools, and log management:

Status Indicators: Displays total configured slots, active/busy worker tabs, and server uptime.
Launch Workers: Configure active slot counts for Grok, Gemini, and ChatGPT. Clicking "🚀 Load Workers" dynamically opens or safely closes Stealth browser tabs in the background.
Default URLs: Set default starting web URLs for each platform. Saving updates config.json and adjusts the active browser tabs.
URL Management (per Job Key): Manage conversation session URLs mapped to NaModu keys (e.g. OCtest). Set fixed, time-based, or usage-based cache TTL/limits, or delete keys to reset sessions.
Log Management: Filter system log exports by caller faction (OC, CD, or custom), dynamically add new caller prefixes via the + button (writes to data/caller_map.json and invalidates memory cache instantly), and clear log files.

2. Main Console (Right)

Worker Slots Status: Real-time cards showing the current state (Idle, Busy with prompt details, or Offline) of every active Chromium tab. Status badges indicate the platform (Grok, Gemini, or ChatGPT).
JSON Output: Live view displaying raw JSON response structures of the last completed job, including total execution times and session URLs, with a quick-copy button.
System Logs: Streaming log console showing color-coded background process logs (API requests, browser automation actions, and errors) directly from the server.

📡 API Usage

Core of Potato accepts standard OpenAI Chat Completions requests. The user identity must follow the NaModu format (6 alphanumeric characters: 2-character caller prefix + 4-character module tag, e.g., OCtest). Core of Potato reads the NaModu from the request using 4 methods, tried in this priority order:

Priority	Method	How to Pass
1	JSON Body	`"user": "OCtest"` in the request JSON payload
2	Bearer Token	`Authorization: Bearer OCtest` header
3	X-User Header	`X-User: OCtest` header
4	User Header	`User: OCtest` header

The first non-empty value found is used. If none are provided, the request is rejected.

Blocking Completion (cURL)

curl -X POST http://localhost:2809/v1/chat/completions \
     -H "Content-Type: application/json" \
     -H "Authorization: Bearer OCtest" \
     -d '{
       "model": "grok-fast",
       "messages": [
         {"role": "user", "content": "Explain quantum computing in one sentence."}
       ]
     }'

Streaming Completion (cURL)

curl -X POST http://localhost:2809/v1/chat/completions \
     -H "Content-Type: application/json" \
     -H "Authorization: Bearer OCtest" \
     -d '{
       "model": "grok-fast",
       "messages": [
         {"role": "user", "content": "Write a short poem about code."}
       ],
       "stream": true
     }'

Models Supported

Use the following values for the "model" field in completions:

grok: Grok (xAI)
gemini: Google Gemini
chatgpt or gpt: OpenAI ChatGPT

Note on Advanced Modes (Fast vs. Expert, Auto, etc.): Core of Potato no longer attempts to force platform-specific modes (like Grok Fast or Expert) via API model names. In practice, automated selection is unreliable and can lead to unexpected behavior (e.g. Fast mode giving poor answers, or Expert mode taking far too long for simple questions).

Recommended Setup: Log in to the respective AI provider's web interface for each of your Browser Slots, select the model/mode that works best for your use case (e.g., set Grok to Auto or Expert, or set ChatGPT to GPT-4o), and leave it. Core of Potato will simply use whichever model is currently active in that browser session.

NaModu Formatting & Validation

Etymology: The term "NaModu" represents a combination of Na (Nation/Faction/Name prefix) and Modu (Module/Caller suffix), forming a 6-character session workspace tag.
Format: The user identifier (passed via any of the 4 methods listed above) must be exactly 6 alphanumeric characters.
- Na (2 characters): The caller prefix (e.g., OC for OpenClaw, CD for OpenCode).
- Modu (4 characters): The module identifier (e.g., test for testing, demo for demo).
Validation: When a request is received, Core of Potato extracts the Na prefix and validates it against data/caller_map.json. If the prefix is not registered, the server immediately rejects the request with an HTTP 400 Bad Request error. New callers can be added dynamically using the + button in the Control Panel Hub UI, which writes to data/caller_map.json and immediately invalidates the server cache.

Concurrency & Queueing Mechanism

To prevent race conditions, overlapping prompts, and browser session corruption on the AI chatbot platforms (such as Grok, Gemini, ChatGPT), Core of Potato implements a state-aware concurrency queueing mechanism:

Same NaModu + Same Model (e.g., two concurrent requests for OCtest using grok):
- These requests share the same conversation URL key (OCtest_grok).
- Core of Potato serializes these requests. The first request takes the available slot. The second request is queued and waits until the first job completes.
- Once the first job finishes and updates the conversation URL in the database, the second job resumes, fetches the latest conversation URL, navigates to it, and runs sequentially.
Same NaModu + Different Models (e.g., OCtest using grok and OCtest using gemini at the same time):
- These requests have different conversation contexts and URLs (OCtest_grok vs OCtest_gemini).
- They are processed as two separate streams in parallel on their respective platform worker slots (no queue wait, unless all slots for that platform are busy).
Different NaModus (e.g., OCtest and OCdemo both using grok at the same time):
- These are treated as independent users.
- They run in parallel on separate slot pages (e.g., grok-1 and grok-2), as long as multiple slots are configured.

🔒 Session URL Caching & Expiry Modes

To maintain session continuity across independent HTTP completions requests, Core of Potato persists conversation URLs in data/jobs.json. When a user requests a completion, the browser manager loads the last stored URL for that specific key. To prevent memory bloat and stale threads, Core of Potato supports three session caching behaviors, configurable per key or via global defaults:

Fixed (fixed):
- The session URL is stored permanently and never expires.
- Ideal for long-term project threads or dedicated system testing sessions.
Time-Based (time_based):
- The session URL is discarded when its age exceeds url_default_ttl_minutes (default: 30 minutes) since the last usage.
- Ideal for temporal context memory that naturally degrades over time.
Usage-Based (usage_based):
- The session URL expires and gets deleted after being reused url_default_max_uses times (default: 10 times).
- Ideal for bounded workflows or strict execution scripts.

These parameters can be configured dynamically per caller key via the Hub UI dashboard or through the /api/url/config REST endpoint.

📡 Complete REST API Reference

All administrative endpoints (marked with 🔑) require authentication. Clients must provide the configured X-Admin-Token header: X-Admin-Token: <your-admin-token> (or be requested from the same origin as the Hub UI dashboard).

Public Endpoints

1. API Health Check

Path: GET /api/health
Description: Returns server state, version info, active worker counts, and server uptime.

Response:

{
  "status": "ok",
  "version": "1.0.1",
  "uptime_seconds": 120,
  "jobs_today": 5,
  "adapter": "Core of Potato",
  "port": 2809,
  "workers": { "grok": 3, "gemini": 1, "chatgpt": 2 },
  "timestamp": "2026-06-06T09:41:00Z"
}

2. Get Job Result

Path: GET /api/jobs/{job_id}
Description: Polls the status of a specific background chat completion job.

Response:

{
  "status": "completed",
  "jobId": "job_123456",
  "response": "Here is the response from the AI...",
  "elapsed_seconds": 12.4,
  "session_url": "https://grok.com/chat/abc-123"
}

3. Retrieve Page Screenshot/Image

Path: GET /api/image/{img_id}
Description: Returns binary image data (e.g. PNG screenshots) stored in memory, useful for visual status checks.

Admin/Management Endpoints (🔑 Requires Admin Token)

4. System Status

Path: GET /api/status
Description: Comprehensive diagnostic status of the server and all active Playwright worker slots.

5. Configure Session Expiry

Path: POST /api/url/config

Request Payload:

{
  "key": "OCtest_grok",
  "mode": "usage_based",
  "ttl_minutes": 30,
  "max_uses": 5
}

Description: Configures custom TTL and usage limits for a specific session URL.

6. Delete Session URL

Path: DELETE /api/url/{key}
Description: Discards the cached session URL mapped to {key}, forcing the next request to spawn a fresh thread.

7. Clear All Sessions

Path: POST /api/url/clear_all
Description: Discards all cached conversation URLs in data/jobs.json.

8. List Session Configurations

Path: GET /api/url/configs
Description: Returns details on all currently cached URLs, usage counts, and expiry times.

9. Get Log Summary

Path: GET /api/logs
Query Parameters: ?date=YYYY-MM-DD (default: today)
Description: Returns the count of today's completed requests and a list of the last 50 entries.

10. Streaming System Logs

Path: GET /api/logs/system
Query Parameters: ?since=timestamp
Description: Fetches recent color-coded console logs output by the Core of Potato engine.

11. Export JSON Logs

Path: GET /api/logs/export
Query Parameters: ?date=YYYY-MM-DD&caller=caller_name
Description: Exports the full structured logs database for the given date, optionally filtered by caller (e.g., OC).

12. Retrieve Specific Log Entry

Path: GET /api/logs/detail
Query Parameters: ?id=request_id
Description: Returns all logs, execution times, and payload properties for a single request.

13. Clear All Logs

Path: POST /api/logs/clear
Description: Erases historical logs databases from the server filesystem.

14. List Worker Slots

Path: GET /api/slots
Description: Returns statuses of all workers (whether they are Idle, Busy with a job, or Offline).

15. Manage Default Landing URLs

Path: GET / POST /api/default-urls

Request Payload (for POST):

{
  "grok": "https://grok.com",
  "gemini": "https://gemini.google.com/app",
  "chatgpt": "https://chatgpt.com"
}

Description: Updates and saves default home URLs for each chatbot in config.json.

16. Manage Caller Authorization Map

Path: GET / POST /api/caller-map

Request Payload (for POST):

{
  "OC": "OpenClaw",
  "CD": "OpenCode",
  "UX": "CustomClient"
}

Description: Read or modify the mapping of 2-character caller prefixes to client names. Updates data/caller_map.json and clears the memory cache instantly.

17. Toggle Headless Visibility

Path: POST /api/browser/toggle-visibility
Description: Dynamically toggles browser visibility. Terminates active Chromium sessions, flips the headless flag, spawns a new Chromium context with reversed headed/headless settings, and recovers all active worker page states.

18. Hot-Reload Workers Config

Path: POST /api/config

Request Payload:

{
  "workers": {
    "grok": 4,
    "gemini": 2,
    "chatgpt": 2
  }
}

Description: Safely opens or closes browser slots on the fly to match the requested numbers, saving settings to config.json without rebooting the server.

🛠️ Extending Core of Potato: Adding Custom Drivers

Core of Potato uses an extensible driver architecture. All automation drivers reside under core/drivers/ and inherit from BaseDriver defined in core/drivers/base.py.

To add support for a new chatbot platform:

Create the Driver Class: Create a new file (e.g., core/drivers/mybot.py) implementing the abstract methods:

from core.drivers.base import BaseDriver

class MyBotDriver(BaseDriver):
    async def send_prompt(self, prompt: str) -> None:
        # Locate input element, type prompt, and trigger send (click/enter)
        pass

    async def wait_for_response(self) -> str:
        # Poll DOM selectors until reply text is fully generated and stable
        pass

    async def wait_for_response_streaming(self):
        # Yield partial text chunks as they appear in the DOM
        pass

Register the Driver: Import and register your class inside core/drivers/__init__.py:

from .mybot import MyBotDriver

DRIVERS = {
    # ... existing
    'mybot': MyBotDriver
}

Define Model Mapping: Link model names to your driver in core/server.py under the MODEL_MAP dictionary (e.g., "mybot": ("mybot", "auto")).

🧪 Testing

We use pytest for integration and unit testing:

pytest

To run lint checks:

ruff check .

🤝 Contributing

Contributions are welcome! Please check our Contributing Guidelines for details.

⚖️ License & Disclaimer

This project is licensed under the MIT License - see the LICENSE file for details.

Refer to DISCLAIMER.md for terms regarding the educational and personal research nature of this tool.
