CommStudio is a Qt 6 desktop workbench for embedded, industrial-control, IoT, and device engineers. It brings Serial, Modbus, Bluetooth, and Network debugging into one native C++ / Qt Quick application with a shared traffic terminal, codecs, automation, and runtime log.

Highlights

  • Serial — port discovery, full communication parameters, HEX/text and escape sequences, line endings, auto reconnect, timed sending, raw file chunks, DTR/RTS/Break, pin state, and byte statistics.
  • Modbus — RTU/TCP master, common function codes, retries, polling tasks, value decoding/encoding, register table, response parsing, and RTU/TCP slave simulation.
  • Bluetooth — adapter status, BLE/Classic scan, GATT read/write/notify, Nordic UART preset, and Classic RFCOMM (SPP).
  • Network — TCP client/server and UDP, client sessions, unicast/broadcast/ multicast, application framing, and auto-reply rules.
  • Shared tools — traffic terminal, command history, HEX/ASCII conversion, checksums, run log, light/dark themes, and English/Chinese UI switching.

Language

The application starts in English. Open Settings → Language and choose English or 中文; the choice applies immediately and is remembered for the next launch.

This README defaults to English. Use the link at the top to switch to the Chinese edition and back.

Build and run

Requirements: Qt 6.6.3 msvc2019_64, Visual Studio Build Tools, CMake, and Ninja.

# Build, deploy Qt runtime files, and synchronize dist.
powershell -NoProfile -ExecutionPolicy Bypass -File scripts\build.ps1 -RunTests

# Create a self-contained package in dist\CommStudio.
powershell -NoProfile -ExecutionPolicy Bypass -File scripts\package.ps1

For a development launch:

$env:PATH = "E:\QT\6.6.3\msvc2019_64\bin;$env:PATH"
.\build-msvc\CommStudio.exe

Project layout

src/
  main.cpp             Application entry point and QML singleton registration
  core/                Traffic model and protocol/codec utilities
  managers/            Serial, Modbus, Bluetooth, Network, settings, and logs
qml/
  Main.qml             Main window, navigation, status bar, and toast
  I18n.qml             English/Chinese UI language helper
  Theme.qml            Shared visual design tokens
  components/          Reusable controls, terminal, and send panel
  pages/               Assistant pages, tools, log, and settings
resources/             Windows application icon resources
tests/                 Core unit tests

Runtime notes

  • Theme and language preferences are persisted with QSettings under HKCU\Software\TBEA\CommStudio.
  • A Bluetooth “Dummy backend running” message means the selected Qt Bluetooth package lacks a usable Windows backend; scanning and connecting will then be unavailable.
