OpenXiv

A preprint server that lives in your social feed.
Built on the AT Protocol. Preprints federate to Bluesky.
openxiv.net · ISSN 3120-9556 (online) · Wikidata Q139860032

OpenXiv is an AT Protocol App View for science. Papers, threads, endorsements, disclosures, and reviews are real app.openxiv.* records that live in each author's PDS (Bluesky's or their own) and federate to the wider AT Protocol network. The server publishes to Bluesky, exposes OAI-PMH 2.0 for library indexers, and runs its own custom Bluesky feeds.

Open to independent researchers without institutional backing. Sign in with ORCID, Google, or did:plc through Bluesky. No endorsement gate. No "must be affiliated" filter.

AI use is welcome under structured disclosure (none, assistant, coauthor, primary, recorded as an app.openxiv.disclosure record). Unverified output is refused with a public refusal packet that names the failure mode. Work returns for revision instead of triggering an author ban.

The instance at openxiv.net is the single live deployment. It is also indexed by BASE, CORE, and the Bluesky directory of custom feeds.

What you actually get

Stack

• Language: TypeScript strict, Node 22.
• API: Fastify 5 with fastify-type-provider-zod for end-to-end typed routes.
• Database: PostgreSQL 16 + pgvector via Drizzle ORM. Migrations live in packages/db/drizzle.
• Queues: BullMQ on Redis 7. Heavy work (compile, embed, explain, figure extraction, Bluesky bridge, jetstream relay) runs in a separate worker process.
• Storage: S3 compatible. MinIO locally, Hetzner Object Storage in production, accessed through @aws-sdk/client-s3.
• LaTeX to PDF: tectonic running in a sandboxed Docker container (mockable).
• LaTeX to HTML: latexml (mockable). PDF and HTML are served side by side on the paper page.
• Metadata extraction: GROBID over its HTTP API for affiliations, references, abstracts.
• Figure extraction: pdf-lib plus a custom raster pass; each figure lands at /api/papers/{id}/figures/{n}.
• LLM: DeepSeek V4 Flash for explainer tier generation; Gemini gemini-embedding-001 for semantic similarity.
• Undisclosed AI detector: ensemble (perplexity burst + Binoculars-style ratio + stylometric) producing a score in [0, 100]. The MVP ships a heuristic; swap in GPT-2-medium scoring when the model directory is populated.
• Auth: OAuth via ORCID (primary, verifies researchers), Google, and Bluesky, all resolving to an AT Protocol DID. Mastodon link-only for cross-posting.
• Web: Astro 5 server-rendered with React 19 islands for the submission wizard, the explainer tabs, the publish action, and the discussion thread.
• Lexicons: app.openxiv.* records in packages/lexicons with JSON schemas and matching zod validators.
• Errors: neverthrow Result types end to end. No silent catches.
• Resilience: opossum circuit breakers wrap every external (LLM, GROBID, tectonic, S3, ORCID, Bluesky PDS, jetstream). A single dependency going down does not take the system out.
• Edge: Caddy 2 in front of every service. Automatic HTTPS, HTTP/3, on-the-fly compression.
• Observability: Sentry SDK with SENTRY_DSN opt in; pino logs with pino-pretty in dev.

Repository layout

openxiv/
  apps/
    api/              Fastify API + BullMQ workers (one image, two entrypoints).
      src/
        routes/       REST endpoints: auth, papers, posts, feed, uploads,
                      profiles, follows, endorsements, refusals, oai-pmh,
                      bsky-feed-generator, bsky-labeler, jetstream relay,
                      starter pack, daily-brief, search, topics, lens,
                      analytics, engagement, account-linking, did-web,
                      preregistrations, paper-edit, moderation, versions.
        services/     Application logic (submissions saga, feed, explain,
                      posts, users, social-push, jetstream-subscriber,
                      Trust Passport assembly, refusal packets, mastodon
                      crosspost, etc).
        workers/      BullMQ workers (compile, embed, explain, figures,
                      pdf-finalize, bsky-follow, mastodon-crosspost).
        plugins/      Fastify plugins (auth, error handler, OpenAPI).
        auth/         Session JWT signing, OAuth state, did:plc resolver.
        scripts/      Operator CLIs (sample-cover, register-bsky-feeds,
                      bsky-smoke, finalize-all-papers, figures-extract-all,
                      rasterize-brand).
        services/brand/  PDF cover assets (logo + masthead bitmaps).
        context.ts    DI bag: db, redis, clients, repos.
        index.ts      API entrypoint.
        worker.ts     Worker entrypoint, same context + services.
      Dockerfile      Multi-stage; tini-supervised; runs migrations on
                      first start.

    web/              Astro 5 SSR + React islands.
      src/
        pages/        /, /submit, /abs/[id], /@[handle], /auth/sign-in,
                      /about, /faq, /press, /policies/*, /terms, /privacy,
                      /dmca, /transparency, /glossary, /vocabulary,
                      /browse, /feeds, /feed.atom, /sitemap.xml, /stats,
                      /search, /topics/*, /compare, /lens/*, /docs/*,
                      /prereg/*, /embed/*, /admin/*.
                      /api-proxy/[...path] proxies browser to API so
                      cookies stay same-origin.
        components/   PaperRow, PostRow, AiBadge, Explainer, SubmissionWizard,
                      PublishButton, TrustPassportPanel, RefusalRow,
                      Provenance Timeline, EmbedCard, MastodonLink.
        layouts/      Base.astro with global head, JSON-LD,
                      RSS auto-discovery.
        lib/          api.ts (typed REST client), format.ts, jsonld.ts.
      public/
        brand/        logo-mark.svg, logo-full.svg, og-default.svg.
        humans.txt, llms.txt, llms-full.txt, manifest.json, opensearch.xml,
        robots.txt, oauth client metadata, schemas/*.json.
      Dockerfile      Multi-stage; serves with @astrojs/node standalone.

    feed-generator/   Standalone Bluesky custom-feed service.
      src/index.ts    Implements
                        /.well-known/did.json,
                        /xrpc/app.bsky.feed.describeFeedGenerator,
                        /xrpc/app.bsky.feed.getFeedSkeleton.
                      Six feeds: openxiv-latest, openxiv-featured,
                      openxiv-questions, openxiv-disclosed,
                      openxiv-beginner, openxiv-claims. Skeletons
                      reference the bridged `app.bsky.feed.post` URIs
                      so the Bluesky App View hydrates embed cards.

    extension/        Chrome / Edge / Firefox MV3 content script.
      manifest.json   Permission limited to arxiv.org/abs/*.
      content.js      Reads arXiv id, calls
                      ${API_BASE}/api/lookup?arxiv_id=...; if matched
                      shows Trust Passport lane badges in a corner
                      sidebar; otherwise a "submit to OpenXiv" CTA.

  packages/
    shared/           AppError, Result helpers, zod env schema, category
                      taxonomy, TID/at-uri ids, OpenXiv id formatter,
                      ISSN constants.
    lexicons/         JSON schemas in schemas/, zod validators in src/.
                      paper, summary, disclosure, post, review,
                      endorsement, citation, preprint, prereg.
    db/               Drizzle schema (users, papers, paper_versions,
                      paper_figures, paper_extras, paper_edits, posts,
                      follows, reviews, refusals, embeddings, jobs,
                      identity, social, bluesky, events, external,
                      featured, profile-cards, profile-modes).
                      Repositories + migration runner + index migrations.
    clients/          External integrations. Each has a real impl, a mock
                      impl, and a factory that picks via env flags.
                      storage (S3), llm (DeepSeek + Gemini), compiler
                      (tectonic), latexml, grobid, oauth (ORCID, Google,
                      Bluesky), pds (AT Protocol PDS client), detector
                      (AI ensemble), keywords (KeyBERT-style).
                      opossum circuit breaker wrapper, HTTP helper with
                      timeout + retry.

  e2e/                Playwright E2E against the docker-compose stack.
  docs/               ARCHITECTURE, ops runbook, dev onboarding,
                      policies, incidents, GITHUB-RELEASE-PREP,
                      security audit, release checklists.
  scripts/            Server bootstrap scripts (Contabo VPS),
                      live-preflight checks (Mastodon, LaTeXML).
  docker-compose.yml             Local dev stack.
  docker-compose.production.yml  Contabo production stack.
  Caddyfile                      Local dev edge.
  Caddyfile.production           Production edge config.
  .github/workflows/             CI: typecheck + lint + unit tests on
                                 Node 22 and 24; E2E via docker-compose.
  _legacy/                       Previous Python + Next.js prototype,
                                 kept for reference only.

Lexicons (app.openxiv.*)

JSON schemas live in packages/lexicons/schemas/. Zod validators live in packages/lexicons/src/.

Submit saga (6 stages)

The submit wizard hands off to a BullMQ saga. Each stage is idempotent and persists its outcome in submission_sagas. A per-stage retry endpoint is available to the submitter and to admins.

1. S1 ops_created: compile (tectonic), upload PDF + HTML to S3, run GROBID for metadata, extract keywords with the KeyBERT-style client, run the undisclosed-AI detector when level=none.
2. S2 ops_approved: transition status to pending_review (single-instance MVP auto-approves; replace with a moderator gate once the instance opens up).
3. S3 id_assigned: atomic allocation of openxiv:{primary_category}.{year}.{NNNNN}.
4. S4 pds_paper: com.atproto.repo.putRecord of app.openxiv.paper into the author's PDS, status flips to published.
5. S5 pds_summary_disclosure: app.openxiv.summary + app.openxiv.disclosure records into the author's PDS.
6. S6 bluesky_bridge: app.openxiv.post referencing the paper, persisted locally so it shows in the OpenXiv feed and is mirrored to the author's app.bsky.feed.post bridge record.

OAI-PMH and library indexing

The OAI-PMH 2.0 endpoint is at https://openxiv.net/oai-pmh.

Supported verbs: Identify, ListMetadataFormats, ListSets, ListIdentifiers, ListRecords, GetRecord. Metadata format: oai_dc. Deleted-record strategy: transient. Resumption tokens are stateless and embed until, from, set, and metadataPrefix so harvesters can resume mid-page without server state.

The endpoint is validated by BASE OVAL and indexed by:

• BASE, Bielefeld Academic Search Engine.
• CORE, Open Access aggregator.
• Bluesky directory of custom feeds.
• Wikidata, preprint server entry with ISSN, language, country, headquarters, Bluesky handle.

OpenDOAR submission is in progress.

Bluesky feed generator

apps/feed-generator/ is a standalone Fastify service that serves the Bluesky feed-generator XRPC surface:

GET /.well-known/did.json                              did:web document
GET /xrpc/app.bsky.feed.describeFeedGenerator          lists feeds
GET /xrpc/app.bsky.feed.getFeedSkeleton?feed=at://...  returns skeleton

Six feeds are published under did:web:openxiv.net:

• openxiv-latest: every new paper as it lands.
• openxiv-featured: editor picks.
• openxiv-questions: open questions from researcher threads.
• openxiv-disclosed: papers with explicit AI disclosure (assistant and above).
• openxiv-beginner: papers with the strongest "school tier" explainer score.
• openxiv-claims: papers with at least one typed verified-derivation or reproduced-result endorsement.

The skeleton references the bridged app.bsky.feed.post URIs (paper_versions.bsky_post_uri) so the Bluesky App View hydrates embed cards natively.

arXiv overlay browser extension

apps/extension/ is an MV3 content script for Chrome, Edge, and Firefox. On any https://arxiv.org/abs/* page it injects a sidebar with the matching OpenXiv paper's Trust Passport lane badges, or a "submit to OpenXiv" CTA if there is no match.

Install in developer mode:

1. Open chrome://extensions or the browser equivalent.
2. Enable Developer mode.
3. Load unpacked, point at apps/extension.
4. Open the extension's Options page and set the API base URL (default http://localhost:4000 for dev).
5. Visit any arxiv.org/abs/{id} page.

Icons (icon-16.png, icon-48.png, icon-128.png) are placeholders; swap before publishing to the Web Store.

Quick start (Docker)

cp .env.example .env       # the defaults already match docker-compose
docker compose up --build  # first build ~3 min, subsequent starts ~10s

After the stack is healthy:

• Web: http://localhost:4321
• API + OpenAPI docs: http://localhost:4000/docs
• OAI-PMH: http://localhost:4000/oai-pmh?verb=Identify
• Feed generator: http://localhost:4400/.well-known/did.json
• MinIO console: http://localhost:9001 (minioadmin / minioadmin)
• GROBID: http://localhost:8070
• Postgres: postgres://openxiv:openxiv@localhost:5432/openxiv
• Redis: redis://localhost:6379

Drizzle migrations run automatically on first start (packages/db/drizzle/0000_init.sql and later).

Mock clients are on by default (USE_MOCK_CLIENTS=true) so the full submit pipeline works without Gemini, ORCID, or a real tectonic image. Switch them off individually as you wire real providers.

Happy path, end to end

1. Visit http://localhost:4321/auth/sign-in and pick Continue with ORCID (mock; instantly logs you in as a seeded test author).
2. Go to /submit and walk through the 6-step wizard. Drop any .tex, .pdf, or .tar.gz as the source.
3. The API stores source to MinIO, creates a papers row in compiling state, writes the disclosure + summary, ensures a submission_sagas row, and enqueues a BullMQ saga job.
4. The worker runs the 6-stage saga, marking each stage done in submission_sagas.
5. Paper page is at /abs/{openxiv-id} (for example /abs/cs.AI.2026.00001). The page shows the AI-disclosure badge, the three explainer tabs (school, undergrad, expert), the Trust Passport, the Provenance Timeline, and per-stage retry buttons for the submitter and admins.
6. Owner profile lives at /@{handle} with unified All / Papers / Posts tabs, ORCID and moderator badges.

Development

pnpm install
pnpm dev                # API only (port 4000)
pnpm dev:web            # Web only (port 4321)
pnpm dev:workers        # Worker only
pnpm dev:all            # All apps in parallel

pnpm typecheck
pnpm lint
pnpm test               # unit + property tests across the workspace
pnpm test:e2e           # Playwright happy path (requires docker compose up)
pnpm build              # build all packages then all apps
pnpm format             # prettier

Run migrations against a local Postgres without containers:

DATABASE_URL=postgres://openxiv:openxiv@localhost:5432/openxiv \
  pnpm db:migrate

Regenerate a new migration after editing the Drizzle schema:

pnpm db:generate

For a first-day setup checklist, see docs/dev/ONBOARDING.md. For production restart, secret rotation, and restore steps, see docs/ops/RUNBOOK.md.

Configuration

All config is validated by packages/shared/src/env.ts (zod) on startup. In production the app fails fast on unsafe mock flags, wildcard CORS, localhost public bases, missing required provider credentials, and default MinIO credentials. See .env.example for the full list. Highlights:

• USE_MOCK_CLIENTS=true flips every external to its in-process mock.
• USE_MOCK_LLM, USE_MOCK_GROBID, USE_MOCK_TECTONIC, USE_MOCK_LATEXML, USE_MOCK_DETECTOR, USE_MOCK_ORCID, USE_MOCK_BLUESKY toggle individual services.
• DETECTOR_*_WEIGHT re-weights the undisclosed-AI ensemble.
• ADMIN_DIDS and SUBMIT_ALLOW_DIDS are comma-separated DID lists for admin and submit gates.
• JETSTREAM_URL points at the public Bluesky jetstream relay for the firehose subscriber.
• OPENXIV_FLAG_LEGACY_UNPREFIXED_MOUNT=0 retires the legacy unprefixed API surface (default 1 during the migration window).

Tests

• Unit (vitest): every package and app has a test script. Run all with pnpm test.
• Property-based (fast-check): invariants on the disclosure lexicon (packages/lexicons/src/disclosure.property.test.ts). Non-none levels must populate aiUsed and models. none must leave them empty. Cross-listing rules on the paper lexicon are property tested in paper.crossListings.test.ts.
• Contract: JSON lexicons are validated against the corresponding zod schemas via the validator tests in packages/lexicons.
• Integration: route-level tests under apps/api/src/routes/*.test.ts cover the OAI-PMH verbs, the Bluesky starter pack, the moderation flow, account linking, profile assembly, and the events log.
• E2E (Playwright): e2e/tests/happy-path.spec.ts drives the full flow. Sign-in, submit, poll for worker completion, publish, see on home feed.

CI runs the unit job on Node 22 and 24, then the E2E job through docker compose up. See .github/workflows/ci.yml.

Production deployment

The single live instance runs on a Contabo Cloud VPS with Caddy 2 in front of docker-compose.production.yml. The compose file pins the API to the multi-stage image built from apps/api/Dockerfile and the web to apps/web/Dockerfile; workers reuse the API image with a different entrypoint (worker.ts). The feed generator runs as its own service so it can be put behind its own subdomain.

Backups: nightly pg_dump to an off-site S3, snapshot retention 30 days. Object storage in production is Hetzner Object Storage, S3-compatible, region eu-central.

Observability is opt-in. Set SENTRY_DSN to ship server errors. Logs are JSON via pino in production; dev uses pino-pretty.

For the full topology, see docs/ARCHITECTURE.md. For incident response and rotation, see docs/ops/RUNBOOK.md.

Single-owner mode

OpenXiv MVP is a single-instance deployment with one owner who is also the only moderator. Wire it via env:

ADMIN_DIDS=did:plc:zxyourblueskydid000000001
SUBMIT_ALLOW_DIDS=did:plc:zxyourblueskydid000000001

On first sign-in the owner's DID is auto-promoted to moderator and shown with a badge in the header. With SUBMIT_ALLOW_DIDS set, only listed DIDs can hit POST /api/submissions and random visitors get a 403. Leave it empty for open submissions.

Auth flows

• Mock (default in dev): the OAuth authorize endpoint returns a relative URL with a base64-encoded test profile in code. The Astro app proxies /api-proxy/auth/dev/mock-callback to the API so cookies land on the web origin. Logging in instantly creates A. Author and starts a session.
• ORCID (real): register at https://orcid.org/developer-tools or https://sandbox.orcid.org/developer-tools for testing. Set ORCID_CLIENT_ID, ORCID_CLIENT_SECRET, ORCID_USE_SANDBOX=true for sandbox, and flip USE_MOCK_ORCID=false. Callback URL must match the public web base, for example https://openxiv.net/api-proxy/auth/orcid/callback.
• Google (real): register at https://console.cloud.google.com/apis/credentials. Set GOOGLE_CLIENT_ID, GOOGLE_CLIENT_SECRET. Callback ${PUBLIC_WEB_BASE}/api-proxy/auth/google/callback.
• Bluesky (real): AT Protocol OAuth (client metadata URL or pre-registered client id). The wire format sits in packages/clients/src/oauth/bluesky.ts; production should adopt @atproto/oauth-client-node for DPoP, PAR, and refresh rotation.
• Mastodon (cross-post link only): the auth-mastodon route lets an authenticated OpenXiv user link a Mastodon account so the optional cross-post worker can mirror new paper posts to a Mastodon instance.
