Graph-Orchestrated Agent Loop — a production-grade framework for building LLM applications on top of LangGraph. It gives you two complementary ways to build:

  • Visual-first workflows — design a flow in Dify's drag-and-drop editor, then transpile the exported DSL into a runnable, version-controllable LangGraph Python file with one command. No lock-in to Dify's runtime.
  • Code-first agents — build ReAct / Deep / custom agent loops with the bundled agent_kit SDK (vendored under src/agent_kit/), complete with middleware, model routing, failover, skills, and observability.

Because plain workflow graphs and plain agent loops each have limits, the framework is designed so you can combine them: a graph node can host an agent loop, and an agent can call sub-workflows as tools.

[!NOTE] Lean footprint, real concurrency. In load testing, a two-replica deployment on just 2 vCPU / 4 GB RAM per replica sustained 100 concurrent conversations with no measurable regression in time-to-first-token. The streaming pipeline is async and I/O-bound end to end, so throughput scales with replicas rather than demanding heavier boxes.

[!WARNING] Before you publish this repository publicly, read docs/security-and-open-sourcing.md. The .env* files are no longer tracked (a .env.example template ships in their place), but real credentials still live in git history — they must be scrubbed (git filter-repo) and rotated before the first public push. Internal service URLs are also still hard-coded in a few places.

Why this framework

Need What it gives you
Design flows visually, run them yourself Dify DSL → LangGraph .py transpiler (docs/dify-transformer.md)
Rich built-in node library 20+ nodes: LLM, code, HTTP, if/else, classifier, iteration, loop, tool, agent, doc-extractor … (docs/nodes.md)
Swap the wire protocol Pluggable DataAdapter — Dify protocol by default, OpenAI-compatible included, bring your own (docs/protocols-and-adapters.md)
Reusable, LLM-matched capabilities Markdown SKILL.md skills, matched to queries and injected into prompts (docs/skills.md)
Real agent loops vendored agent_kit package: Agent + middleware + harness (docs/agent-kit.md)
Conversation persistence Redis (hot) + MySQL (durable), ES planned (docs/storage-and-config.md)
Streaming, SSE, HITL Token streaming with branch-aware routing, human-in-the-loop interrupts (docs/streaming-and-hitl.md)
Observability Langfuse tracing + memory-leak monitoring
Run cheap, scale horizontally Async I/O-bound pipeline — 100 concurrent conversations on 2 vCPU / 4 GB × 2 replicas with no first-token regression

Documentation map

Start here, then follow the links into the topic files under docs/.

  1. Getting Started — install, configure, run the server, register your first workflow.
  2. Architecture — the big picture: request lifecycle, the three-layer streaming pipeline, how the pieces fit.
  3. Nodes Reference — every built-in node, its purpose, config, and Dify mapping.
  4. Dify Transformer — convert a Dify DSL export into a runnable workflow file.
  5. Protocols & Data Adapters — the interaction-protocol abstraction and how to implement a custom one.
  6. Streaming & HITL — the streaming/SSE model and human-in-the-loop interrupts.
  7. Skills — authoring SKILL.md, matching, and prompt injection.
  8. Agent Kit — the vendored agent_kit SDK: Agent, graph builders, middleware, harness.
  9. Storage & Config — Redis/MySQL persistence, config files, environment variables.
  10. API Reference — HTTP endpoints (chat, workflow, HITL, report, suggested questions).
  11. Security & Open-Sourcing Checklist — read before publishing.
  12. Design Notes & Improvement Suggestions — honest assessment and concrete refactors.

Architecture at a glance

flowchart TB
    subgraph design["Design time"]
        dify["Dify Studio<br/>(visual editor)"]
        transpiler["Dify Transformer<br/>goalflow/tool/dify_transformer/"]
        gen["Generated workflow<br/>class YourWorkflow(BaseWorkflow)"]
        dify -- "export DSL (.yml)" --> transpiler -- "emit .py" --> gen
    end

    client(["Client"])

    subgraph runtime["Run time"]
        direction TB
        http["HTTP layer — goalflow/app.py (FastAPI)<br/>/v1/chat-messages · /v1/workflows/run · /v1/*/suggested · /stop<br/>auth: goalflow/api/auth_validator.py (Bearer token → Workflow)"]
        svc["Generate services — goalflow/workflow/services/<br/>Chatflow / Workflow GenerateService<br/>RunnableConfig · lifecycle chunks · Redis stop-flag poll"]
        engine["Engine — goalflow/workflow/base_workflow.py<br/>BaseWorkflow wraps a LangGraph StateGraph<br/>execute() · stream() · resume() (HITL)"]
        nodes["Node library — goalflow/node/<br/>llm · code · http · if/else · classifier<br/>iteration · loop · tool · agent · doc-extractor …"]
        proc["Chunk processors — goalflow/workflow/chunk_processor/<br/>raw LangGraph stream → semantic events<br/>branch-aware token routing"]
        adapter["Data adapter — goalflow/workflow/services/data_adapter/<br/>AbstractDataAdapter → Dify / OpenAI / custom"]

        http -- "initial_state (BaseState)" --> svc
        svc -- "drives" --> engine
        engine <-- "__call__ / Command / Send" --> nodes
        engine -- "(stream_mode, event) tuples" --> proc
        proc -- "semantic events" --> adapter
    end

    subgraph stores["Side stores"]
        redis[("Redis — cache/<br/>hot messages · conv vars · stop flags")]
        mysql[("MySQL — db/<br/>durable messages · HITL reviews · conv vars")]
    end

    subgraph cross["Cross-cutting"]
        agentkit["agent_kit (src/agent_kit/)<br/>agent loops via goalflow/node/agent_base.py"]
        trace["goalflow/trace/ — Langfuse"]
        monitor["goalflow/monitor/ — memory"]
        llm["goalflow/llm/ — LLM factory"]
    end

    gen -. "registered as" .-> http
    client -- "POST + Bearer" --> http
    adapter -- "SSE  data: {...}" --> client

    svc <--> redis
    engine <--> mysql
    nodes -. "embed / call" .-> agentkit
    engine -.-> trace
    nodes -.-> llm

See docs/architecture.md for the annotated walkthrough of each layer and the full request lifecycle.

Quick glance at the flow

Dify Studio (visual design)
        │  export DSL (.yml)
        ▼
goalflow/tool/dify_transformer/wf_code_generator.py  ──►  your_workflow.py
        │                                              (class YourWorkflow(BaseWorkflow[BaseState]))
        ▼
FastAPI (goalflow/app.py)
  POST /v1/chat-messages ── Bearer token ──► auth_validator maps token → Workflow instance
        │
        ▼
ChatflowGenerateService.generate(state)
        │  drives  BaseWorkflow.stream()  (LangGraph)
        ▼
StreamProcessor (semantic events) ──► DataAdapter (Dify / OpenAI / custom) ──► SSE to client
        │
        ├─ Redis  (message cache, conversation variables, stop flags)
        └─ MySQL  (durable messages, HITL reviews, conversation variables)

See docs/architecture.md for the annotated version.

Requirements

git clone <your-repo-url>
cd goalflow
cp .env.example .env          # then fill in real values

# editable install — puts the `goalflow` package on your path
pip install -e .

goalflow-server                   # serves on http://localhost:8000
# or, without installing:  python start_server.py

The project uses a src/ layout: the framework lives under src/goalflow/ (imports as goalflow.*, e.g. from goalflow.node import LLMNode) and the vendored agent SDK under src/agent_kit/ (imports as agent_kit.*). No git submodules — everything is self-contained. Full setup and environment configuration is in docs/getting-started.md.

Project layout

goalflow/
├── pyproject.toml             # packaging, deps, console script (goalflow-server)
├── start_server.py            # uvicorn launcher (dev, no install needed)
├── bootstrap_paths.py         # sys.path shim so `src/` is importable without install
├── config.yaml                # server/logging config
├── .env.example               # environment template (copy to .env)
├── Dockerfile
├── src/
│   ├── goalflow/                    # the framework package — imports as `goalflow.*`
│   │   ├── app.py               # FastAPI app + all HTTP endpoints
│   │   ├── config.py            # settings, structlog logging, contextvars
│   │   ├── constants.py         # WfNodeType and framework-wide enums
│   │   ├── workflow_types.py    # shared config/type models
│   │   ├── errors.py
│   │   ├── state/               # BaseState (the shared LangGraph state) + reducers
│   │   ├── node/                # built-in node library (+ node/custom/, agent_base.py)
│   │   ├── visitor/             # turns Dify graph nodes into code/objects
│   │   ├── workflow/
│   │   │   ├── base_workflow.py # BaseWorkflow: wraps a LangGraph StateGraph
│   │   │   ├── services/        # generate services + data_adapter/ (protocol layer)
│   │   │   ├── chunk_processor/ # raw LangGraph stream → semantic events
│   │   │   ├── stream/          # answer/end stream routing + template parsers
│   │   │   └── utils/           # checkpointer + connection wrappers
│   │   ├── dify_parser/         # Dify DSL YAML → internal graph model
│   │   ├── tool/                # transpiler, HTTP/SSE clients, OSS, MCP, metrics
│   │   ├── skill/               # skills engine
│   │   ├── llm/                 # LLM factory
│   │   ├── cache/ db/ service/  # Redis + MySQL persistence
│   │   ├── api/                 # auth, HITL, report endpoints
│   │   ├── trace/ monitor/      # Langfuse tracing + memory monitoring
│   │   └── prompts/             # prompt templates
│   └── agent_kit/               # vendored agent SDK — imports as `agent_kit.*`
├── skills/                      # example SKILL.md skills (data, not code)
├── test/                        # unit + integration tests
└── docs/                        # documentation

Status & roadmap

This framework is extracted from an internal production system, so some pieces are opinionated toward that origin (Alibaba Cloud OSS, Qwen/DashScope defaults). The generalizable core — the node library, the Dify transpiler, the adapter abstraction, and the agent kit — stands on its own.

Planned / suggested directions (details in docs/design-notes.md):

  • Migrate durable message storage from MySQL to Elasticsearch.
  • Support visual tools beyond Dify (one-click transpile from other builders).
