Paste a SQL schema (CREATE TABLE statements) → get a clean, interactive ER diagram. Open source and 100% local — it runs entirely in your browser, so your schema never leaves your machine. No server, no signup, no upload. Live at https://sqltoerdiagram.com.

Why

Every other SQL-diagram tool is either paywalled, ugly, or slow. SQL to ER Diagram is a single static page that:

  • Parses CREATE TABLE / ALTER TABLE DDL (MySQL, Postgres, SQL-Server-ish).
  • Renders tables on a canvas with cached bitmaps + viewport culling, so it stays smooth at hundreds of tables (benchmarked ~120fps while zooming 300 tables / 593 FKs).
  • Declutters dense schemas: FK lines are soft by default; hover a table to highlight just its relationships, click to pin focus (fades every unrelated table and line). Click empty space to clear.
  • Edit on the canvas → SQL updates: double-click a table name, column name, or column type to edit it inline. The change is applied as a surgical text edit to your SQL (comments, formatting and unsupported clauses are preserved), and a table rename automatically updates every REFERENCES to it.
  • Add columns: click a table to pin it, then + add column. The new column is inserted into your SQL with a default type for the selected dialect (PostgreSQL / MySQL / SQLite / SQL Server), and opens inline so you can name it. Editing a column type shows dialect-aware type suggestions.
  • Your arrangement is saved: drag tables wherever you like — positions and the camera persist automatically, so reloading restores your exact layout instead of re-arranging. Editing SQL keeps your manual positions; only brand-new tables get auto-placed (beside the rest). Arrange re-runs auto-layout when you want it.
  • Save / Open projects: Save downloads a .json project (SQL + layout + camera
    • dialect); Open loads one back. Keep multiple diagrams or share them.
  • Share link: Share copies a URL with the entire project (SQL + node positions
    • camera + dialect) encoded in the URL hash — gzip-compressed + base64. The data lives in the link itself (the #… fragment is never sent to a server), so sharing needs no backend. Opening the link restores the exact diagram.
  • Annotations (bottom-left palette): add sticky notes and group boxes to label and cluster sections. Drag to move, drag the corner to resize, double-click to edit text, click to select (colour swatches + delete), or press Delete. They're part of the diagram — included in save, share links, and PNG/SVG exports.
  • Overlap-free layout: auto-arrange runs a separation pass so no two tables overlap.
  • Hide the SQL panel (⬚ in the toolbar) for a full-width diagram.
  • Syntax-highlighted SQL editor: keywords / types / strings / comments / numbers are colored via a paint layer behind the textarea. Re-tokenizing is a single linear pass coalesced to one animation frame, so typing stays instant (~6ms full repaint on a 45KB / 300-table script, sub-ms on normal schemas).
  • Lets you drag tables, scroll/pinch to zoom, pan, and smart auto-arrange: hub-aware layered layout (the most-connected table is placed on one side with its related tables aligned beside it), with Horizontal/Vertical direction and Compact/Comfortable/Spacious spacing options under the Arrange ▾ menu.
  • Exports PNG (raster) and SVG (vector).
  • Has light + dark themes, and remembers your last schema locally.

Run locally

npm install
npm run dev      # http://localhost:5173

Build & host

npm run build    # outputs static files to dist/

dist/ is plain static HTML/JS/CSS — drop it on any static host:

  • GitHub Pages — push dist/ to a gh-pages branch, or use an action.
  • Netlify / Vercel / Cloudflare Pages — build command npm run build, publish dir dist.
  • Any web server / S3 bucket — just upload the contents of dist/.

Preview the production build locally: npm run preview.

Supported SQL

  • CREATE TABLE [IF NOT EXISTS] name ( ... ) with quoted / backtick / [bracket] / schema.qualified names.
  • Inline column constraints: PRIMARY KEY, NOT NULL, UNIQUE, REFERENCES other(col).
  • Table-level constraints: PRIMARY KEY (...), UNIQUE (...), FOREIGN KEY (...) REFERENCES other(...), CONSTRAINT ... FOREIGN KEY ....
  • ALTER TABLE x ADD [CONSTRAINT ...] FOREIGN KEY (...) REFERENCES y(...).
  • Line (--, #) and block (/* */) comments are ignored.

Tech

  • Vite — build + dev server.
  • @dagrejs/dagre — layered auto-layout.
  • Custom canvas renderer + SQL DDL parser (no heavy SQL-parser dependency).

Shortcuts

  • ⌘/Ctrl + Enter — re-arrange.
  • Double-click canvas — zoom in.
  • Drag the divider between panes to resize the editor.
