Think with AI beyond the chat box.

PenEcho is a shared canvas where handwriting, equations, diagrams, and spatial context become part of the conversation.

Quick Start • Recommended Models • Architecture • Discord

A Kimi Open Source Friend

PenEcho is an official member of Kimi Open Source Friends, Moonshot AI's program supporting outstanding open source projects. The Kimi team backs PenEcho's development with API credits, and Kimi K3 is one of the recommended models for demanding canvas work — accurate on handwriting, strong on diagrams, and fast in practice.

Using these links directly supports the project:

• Kimi Code — Kimi's coding subscription, available worldwide
• Kimi Open Platform · China — API access for mainland China
• Kimi Open Platform · Global — API access for the rest of the world

Think on the canvas

Put a question, equation, diagram, or half-formed idea anywhere on the canvas and pause. PenEcho reads your marks and their spatial relationships, then answers beside them. You can work through a problem without translating every step into a chat message or rebuilding it with rigid diagram tools.

• Get answers, hints, explanations, continuations, formulas, plots, and diagrams directly on the canvas.
• Drag AI drafts directly on the canvas, resize them by group or axis, copy returned text or formulas, then accept or discard them before they become part of your work.
• Draw naturally with a stylus or mouse, then pan and zoom across a sparse 20,000 x 20,000 canvas.
• Draw a freehand lasso around confirmed ink to move, resize, recolor, delete, or send only that selection to Typeset; ordinary selection edits and cancellation never trigger an AI request.
• Choose Arcane, Sci-fi, Research, or Studio mode to match the kind of problem you are exploring.
• Save lightweight snapshots locally in your browser. Starting a new canvas can overwrite the current snapshot, save a new copy, or continue without saving; unconfirmed AI drafts are never included.
• Export confirmed canvas ink as a cropped PNG with one 512-pixel tile of paper margin on every side.

PenEcho keeps a small local runtime and only allocates 512 x 512 tiles where ink exists, so the huge logical canvas does not become a huge bitmap.

What's new in 0.6.0

• Controllable animated explanations. Declarative animation scenes are enabled by default so the model can use motion when explicitly requested or when it materially improves an explanation. The generic Plugins menu can turn them off, removing the additional 500–600 prompt tokens and restoring the original request and rendering behavior.
• Safe, persistent animation rendering. Transparent Canvas2D scenes support up to 32 objects and 32 motions, play immediately, remain editable before and after confirmation, and persist through snapshots. The renderer uses a separate transparent layer with dirty-region updates, limits the canvas to 20 animations, and never executes model-provided JavaScript.
• Touch- and pen-friendly animation controls. Mouse and pen clicks reveal the full animation toolbar immediately, while touch requires a one-second hold to avoid accidental activation during canvas panning. The toolbar and selection outline hide together after ten seconds, an outside click, or renewed drawing.
• More reliable model output. Requests reserve output headroom, animation dimensions are bounded without encouraging oversized scenes, and the server can recover the first complete JSON response from harmless trailing model output. Invalid, incomplete, disabled, or over-limit animation commands remain rejected explicitly.
• Sharper text and draft rendering. Confirmed text automatically formats safe Markdown and likely LaTeX, with Preview showing the same final result. Large downsampled AI drafts now clip against their logical dimensions, preventing the initial top-left-quarter rendering defect.
• Non-blocking npm updates. Interactive starts bring the service online before checking npm, visibly report the installed version, and stop cleanly after an accepted global update so the upgraded service can be started manually.

Animation scenes in 0.6.0

Animation is a removable plugin rather than a permanent requirement for every PenEcho request. Animation scenes is enabled by default in the canvas toolbar's Plugins menu. Clear its checkbox whenever you want the original static request and canvas behavior; PenEcho remembers that choice.

• When enabled: the model may return an animated demonstration when you explicitly request one or when motion materially clarifies the answer. The additional animation protocol adds approximately 500–600 input tokens to each AI request.
• When disabled: PenEcho omits the animation protocol and plugin field, filters new animation commands, and does not render animation scenes. Static requests and canvas behavior remain the same as before this feature. Previously saved scenes remain stored and become available again if the plugin is re-enabled.
• Transparent by design: animation scenes have no background layer, allowing the paper, handwriting, diagrams, and other canvas content underneath to remain visible.

For example, with the plugin enabled, you can write or ask for an animated orbital model, a moving geometry construction, interacting figures, or another process where change over time is part of the explanation. The model is instructed to choose a size that fits the actual request; 5000 logical units per axis is an upper bound, not a target.

Returned scenes start playing while they are still editable drafts. Move or resize the draft, then accept or discard it like other AI output. After confirmation:

• Click with a mouse or pen to reveal the complete editing controls immediately.
• Touch and hold for one second to reveal them without interfering with ordinary one-finger canvas panning.
• Use the controls to pause or resume, restart, move, resize, confirm an edit, cancel an edit, or delete the scene.
• The toolbar, outline, and resize controls hide together after about ten seconds, an outside click, canvas navigation, a tool change, or a new pen stroke.

Animation scenes are declarative JSON data rendered by PenEcho's own Canvas2D renderer; model-provided JavaScript is never executed. Each scene is limited to 32 objects and 32 motions, and a canvas can contain at most 20 animations. Only visible playing scenes request animation frames, complex visible scenes reduce their refresh rate, and changed screen regions are redrawn independently. Confirmed scenes and playback state are preserved in local snapshots, and enabled animations are captured at a fixed frame in previews, exports, and later model context.

How it works

The browser sends only the relevant canvas crop and geometry. The server validates the request, uses the selected executor, and returns a movable draft that stays separate from confirmed ink until you accept it.

Quick start

You need Node.js 18.17+ and one of the following: an API key, an authenticated Codex CLI, or an authenticated Claude Code CLI.

npm install -g penecho
penecho configure
penecho

Interactive starts print the current version immediately. After the server is listening, PenEcho displays Checking latest PenEcho version... and queries npm without delaying availability. If a newer version exists, press Enter at the default Y prompt to install it globally. The current service then stops without launching a background process; run penecho again when you are ready to start the updated version. When the installed version is current, PenEcho says so explicitly. Offline checks and non-interactive starts continue without blocking the running service.

penecho configure opens the interactive configuration center. Its main menu contains LLM source, Settings, and Exit. Use the arrow keys and Enter to navigate:

• LLM source -> Claude CLI selects a detected, recommended, default, or manually entered model and an effort level. Opus 4.8 or newer is recommended; Sonnet and Opus 4.6 can respond but may produce weaker canvas results.
• LLM source -> Codex CLI selects a model and effort. GPT-5.5 or newer is required for good results, gpt-5.6-sol is recommended, and xhigh is the highest listed Codex effort.
• LLM source -> API selects the OpenAI-compatible or Anthropic/Claude-compatible request format, then asks for the URL, model, effort, and hidden key. Kimi K3 (China / Global) uses the OpenAI-compatible format with model k3; current testing recommends medium. Anthropic API offers none to disable thinking and defaults new configurations to the recommended medium adaptive-thinking level. PenEcho does not set temperature for API requests, connection checks, or CLI invocations; each provider and model uses its own default. Existing values are offered as defaults and a blank key keeps the saved key.
• Settings controls the unified model timeout, the image format sent to every model executor, request recording and retention, listening interface and port, and initial Auto AI delay. WebP is the default; PNG is also available. The delay can also be changed on the canvas.

Every LLM page ends with Test & Save, and PenEcho always saves before checking. Codex CLI uses a fast offline check: it verifies the executable and login, then reads codex debug models --bundled to confirm the selected model exists. It does not run inference, attach an image, refresh the online catalog, or consume model tokens. Claude CLI and API configuration still send one small real request to verify the selected endpoint/model settings. Whether a check passes or fails, the configuration remains saved and the UI returns to the parent menu with a clear diagnostic.

The canvas toolbar exposes a fixed-width clickable Reasoning menu beside Auto AI for frequent per-request changes: Configured, none, low, medium, high, and the provider's highest practical level. Configured omits the per-request effort field so the server preserves the configured custom effort or the underlying CLI default. The last explicit position maps to xhigh for OpenAI API and Codex CLI, and to max for Anthropic API and Claude CLI. none sends OpenAI reasoning_effort=none; for Claude it disables thinking. Model support remains provider-dependent, so an endpoint may reject a level its selected model does not implement. The saved AI_EFFORT initializes this control, while a toolbar change overrides it for subsequent canvas requests without rewriting the configuration file. The menu closes after a selection or five seconds of inactivity.

The default configuration is ~/.penecho/config.env. API credentials are plaintext in this local file, receive owner-only permissions on POSIX systems, and are never sent to browser code. Protect it like any other credential. If penecho is started before this file exists, it opens the configuration center automatically in an interactive terminal.

Use a different env-style configuration file for a particular launch when needed:

penecho configure --config ./team.env
penecho --config ./team.env

An explicit --config file replaces the default global file for that command. PenEcho does not automatically read a project-directory .env or a package-directory .env.

CLI prerequisites

Installing the Codex desktop app alone does not guarantee that a codex executable is available on the shell PATH. Install and authenticate the CLI separately before selecting Codex:

npm install -g @openai/codex@latest
hash -r
codex --version
codex login status

If needed, run codex login. Claude CLI mode similarly requires an installed and authenticated Claude Code CLI, normally through claude auth login.

PenEcho uses the selected CLI locally and does not need an API key for that source. Normal startup checks the executable and login without consuming model tokens. Codex Test & Save additionally verifies the selected model against the installed CLI's bundled catalog without making a model request; Claude Test & Save sends a small real request.

Canvas requests through Codex use codex exec --json. PenEcho returns as soon as Codex emits the final agent message and turn.completed; if the CLI process remains alive afterward, it is terminated and cleaned up in the background instead of delaying the canvas response.

Claude CLI requests use one isolated claude -p turn with tools, agents, MCP, prompt suggestions, session persistence, and other nonessential background traffic disabled. Selecting effort none sets MAX_THINKING_TOKENS=0, causing Claude Code to send thinking.type=disabled; because none is not a valid Claude CLI effort value, PenEcho also passes an internal low effort and per-process --settings override to neutralize any user-level CLAUDE_CODE_EFFORT_LEVEL=max. Selecting low, medium, high, or max leaves thinking enabled and applies the chosen value through both Claude's --effort flag and the same settings override. PenEcho incrementally validates the stream and returns as soon as Claude emits its successful final result; any attempted tool use aborts the request, while a CLI process that remains alive after the result is terminated and cleaned up in the background.

Transient launch overrides remain available:

penecho doctor --codex
penecho --codex --model gpt-5.6-sol --effort xhigh
penecho --claude --model opus --effort max
penecho --port 4000

--model, --effort, and --port apply only to that process and take precedence over the selected configuration file. Omit them to use the saved choice or the underlying CLI default. Other model-specific effort strings are accepted and passed through.

Run from this source directory

Install dependencies and start this checkout through the same production entry point as the installed CLI:

npm install
npm start

The first interactive start opens the configuration center when needed. Arguments after -- are passed to PenEcho, for example npm start -- --port 4000.

To expose this checkout's penecho command globally instead, use:

npm link
penecho configure
penecho

npm link creates the local command link; it does not publish the package. There is no separate build step.

Open http://localhost:3888. With the default 0.0.0.0 listener, startup also prints the machine's concrete LAN URLs on the following lines. Open one of those URLs on another device; if it cannot connect, allow the configured inbound TCP port in the host operating system's firewall or applicable routing policy.

Recommended model configurations

These recommendations balance answer quality against the latency of PenEcho's real canvas workload. They are based on current hands-on testing rather than synthetic benchmarks; actual response time still varies with the provider, canvas complexity, image size, and reasoning behavior.

Google models have not been tested yet. Contributions are welcome: if you try Gemini or another Google model, please share the model ID, provider or executor, reasoning configuration, approximate latency, and a representative canvas example in an issue.

Token use and cost

For a typical PenEcho canvas request, total output usage—including hidden reasoning tokens when the provider reports them—roughly follows the selected effort level:

These are practical estimates rather than enforced PenEcho limits. Actual usage can vary substantially by model, provider, canvas complexity, and reasoning behavior. The cost example below continues to use the typical low case: 10,000 input tokens and 1,000 output tokens. At standard short-context API rates, that would be:

• gpt-5.6-sol: 10,000 x $5.00 / 1M + 1,000 x $30.00 / 1M = $0.080
• gpt-5.6-terra: 10,000 x $2.50 / 1M + 1,000 x $15.00 / 1M = $0.040
• gpt-5.6-luna: 10,000 x $1.00 / 1M + 1,000 x $6.00 / 1M = $0.016

At those example quantities, that is about 1.6 to 8 cents per request. Medium, xhigh, and max requests can cost more because their reasoning tokens are billed as output. Prices can change, so check the OpenAI API pricing page for current rates.

If you sign in to Codex with ChatGPT, PenEcho uses the Codex usage included with your plan instead of an API key. Included limits vary by plan, and additional usage may require ChatGPT credits. See Codex pricing for current plans and limits. Claude CLI mode similarly uses the account authenticated by Claude Code; it is distinct from Anthropic API billing.

Safe deployment

PenEcho listens on 0.0.0.0:3888 by default so localhost and trusted-LAN access work immediately. Choose the deployment boundary that matches your executor:

• Codex CLI and Claude CLI modes: use them only on the local machine or a trusted, directly connected LAN. A valid request starts a local CLI process, so do not expose either mode directly to the public internet or an untrusted reverse proxy. Both work immediately from localhost and LAN addresses without a public-origin setting. PenEcho checks the Host, client network, exact Origin, process-lifetime session cookie, and JSON content type before launching the selected CLI. Each valid new request immediately supersedes the prior request; it never waits in a queue or returns a busy response.
• API mode: local, LAN, proxy, and remote requests are intentionally accepted without PenEcho-level Host or Origin restrictions. If you expose it publicly, place it behind HTTPS, authentication, rate limiting, and request-size controls. Keep the selected configuration file and provider keys private; credentials remain in the Node.js process and are never sent to browser code.

For either mode, keep debug artifacts and request tracing disabled in production unless you are actively diagnosing a problem, and never publish configuration files, logs, screenshots, or saved requests containing private content. When request recording is enabled in Settings, each valid AI request is stored under ~/.penecho/logs/requests by default, including the source atlas.png, the outbound image, credential-redacted request body, raw and parsed responses, fallback details, and final status. The UI also displays this path and configures retention.

Useful configuration

The configuration center writes these settings to ~/.penecho/config.env, or to the file selected with --config:

For installed CLI starts, --model overrides the selected executor's model setting and --effort overrides AI_EFFORT for that process only. Command-line options and process environment variables take precedence over the selected configuration file.

Run the checks before submitting a change:

npm run check

For implementation details, see the architecture notes.
