Loomabase is an open-source, offline-first synchronization engine for applications that use SQLite at the edge and PostgreSQL as their system of record. It is implemented in safe Rust at its core and resolves conflicts at column granularity with deterministic LWW CRDT registers and Lamport clocks. The separate optional C ABI crate necessarily contains audited unsafe boundaries.

Status: production-oriented pre-1.0 engine. The merge, isolation, recovery, authentication, and bounded anti-entropy paths are implemented and tested. The wire protocol remains pre-1.0 and production rollout still requires the environment-specific gates in the production runbook.

Why Loomabase

Most synchronization systems resolve conflicts at row or document level. That causes unrelated offline edits to overwrite each other. Loomabase assigns CRDT metadata to each synchronized column, so a title edited on one device and a completion flag edited on another both survive.

The engine is deliberately transport-agnostic and framework-agnostic. It can sit behind an HTTP, WebSocket, QUIC, or custom embedded transport without mixing network concerns into convergence logic.

Core Guarantees

  • Column-level convergence: independent column updates merge without data loss.
  • Row lifecycle as a CRDT: creation, deletion, and restoration are a per-row last-writer-wins liveness register, so deletes converge and concurrent column edits are preserved across a delete/restore.
  • Deterministic LWW: (lamport_clock, device_id) creates a total order, including concurrent equal-clock writes.
  • Transactional durability: application rows, metadata, and clocks change in explicit SQLite or PostgreSQL transactions.
  • Idempotent cell state: duplicate payload delivery does not change the resulting cells.
  • Race-safe acknowledgement: a newer local write cannot be cleared by an acknowledgement for an older version.
  • Authoritative partial replicas: durable parameterized scopes receive complete membership snapshots and explicit local-only evictions. Overlapping scopes, concurrent in-flight requests, and dirty offline writes are handled without creating global tombstones or losing data.
  • Typed payloads: SQL values retain explicit types through Serde and JSON.
  • Rolling protocol upgrades: the current and previous wire versions are accepted; incompatible payloads are rejected before mutation.
  • Schema-checked sync: every payload carries a deterministic contract fingerprint, so a client and server on mismatched schemas are rejected before any mutation rather than corrupting data.
  • Bounded untrusted input and output: identifiers, values, row/cell counts, clocks, cursors, response pages, columns, and device attribution are validated or capped before mutation.
  • Safe Rust core: unsafe is forbidden in the main crate.
  • Async integration: PostgreSQL uses SQLx async transactions; blocking rusqlite operations run on Tokio's blocking pool behind a Send + Sync facade.

How It Works

Each synchronized cell is a deterministic LWW register:

(todo_id, column_name) -> (typed_value, lamport_clock, device_id)

An incoming value wins when:

incoming.clock > current.clock
OR
incoming.clock == current.clock AND incoming.device_id > current.device_id

SQLite triggers atomically capture local changes in todos_crdt. The PostgreSQL adapter locks the server Lamport clock and affected CRDT rows inside the caller's transaction. Responses are bounded pages of cells written after a server-issued, tenant/device/table-bound cursor.

See Architecture for transaction boundaries, protocol invariants, and trust assumptions. See Vision for the capabilities intended to make Loomabase technically distinct.

Repository Layout

src/
  auth.rs         HS256/RS256 and Supabase JWKS authentication (`server`)
  client.rs       SQLite async facade, delta extraction, and apply logic
  crdt.rs         Typed protocol, validation, LWW ordering, reference merge
  error.rs        Unified typed errors
  http.rs         Optional HTTP surface and pluggable device authentication
  replica.rs      Partial-replica interests, membership, and eviction protocol
  schema.rs       Declarative table contract; generates DDL, triggers, migrations
  server.rs       Transactional, tenant-scoped PostgreSQL adapter
  server_main.rs  `loomabase-server` binary (feature `server`)
tests/
  anti_entropy.rs          Incremental cursor change feed (O(delta) server pull)
  auth.rs                  JWT verification: expiry, tampering, algorithm
  crdt_laws.rs             CRDT delivery-order and atomicity laws
  custom_contract.rs       End-to-end sync of an arbitrary (non-todos) contract
  delete_lifecycle.rs      Tombstone propagation, restore, and liveness LWW
  http_server.rs           HTTP /sync endpoint, auth, limits, and error mapping
  multi_table.rs           Multi-table contract synced per table on one database
  multi_tenancy.rs         Tenant isolation and independent per-tenant clocks
  offline_convergence.rs   Realistic multi-device offline convergence
  postgres_integration.rs  SQLx adapter against a real PostgreSQL instance
  rls.rs                   Row-Level Security isolation via a limited role
  schema_migration.rs      Additive contract migration on an existing database
  security_boundaries.rs   Untrusted-input and spoofing boundaries
  sqlite_atomicity.rs      Trigger, rollback, acknowledgement, async tests
  model_convergence.rs     Randomized reordered/duplicate delivery model
loomabase-ffi/             C ABI bindings (cdylib) for language SDKs

Quick Start

Add the crate from the repository while Loomabase is pre-release:

[dependencies]
loomabase = { git = "https://github.com/loomabase/loomabase" }

Initialize a SQLite client:

use loomabase::Result;
use loomabase::client::SqliteClient;

#[tokio::main]
async fn main() -> Result<()> {
    let client = SqliteClient::open("edge.db", "device-01").await?;
    client
        .create_todo("todo-1".into(), "Ship Loomabase".into(), false)
        .await?;

    let outbound = client.local_delta().await?;
    // Send `outbound` through the authenticated transport.
    Ok(())
}

The recommended integration uses sync_until_caught_up, which keeps transport concerns outside the engine, atomically acknowledges and applies every successful page, and follows bounded server pages until caught up:

# async fn send_to_api(_: SyncPayload) -> Result<SyncPayload> { unreachable!() }
# async fn example(client: &SqliteClient) -> Result<()> {
client.sync_until_caught_up(send_to_api).await?;
# Ok(())
# }

Synchronize a durable partial-replica scope. The server recomputes membership after merging local writes and returns a complete authoritative snapshot. Rows leaving the scope are evicted locally only after dirty writes are acknowledged; eviction never becomes a replicated delete:

# use loomabase::{Result, client::SqliteClient, replica::{PartialReplicaRequest, PartialReplicaResponse, ReplicaInterest, ReplicaPredicate}};
# async fn send_partial(_: PartialReplicaRequest) -> Result<PartialReplicaResponse> { unreachable!() }
# async fn example(client: &SqliteClient) -> Result<()> {
let interest = ReplicaInterest {
    predicates: vec![ReplicaPredicate::IdPrefix("project-a/".into())],
    limit: 10_000,
};
client
    .sync_partial_with("project-a".into(), interest, send_partial)
    .await?;
client.remove_partial_replica_scope("project-a".into()).await?;
# Ok(())
# }

The reference HTTP server exposes normal sync at POST /sync and partial replica sync at POST /sync/partial.

Run the complete two-device library example:

cargo run --example offline_roundtrip

Run the persistent SQLite-to-HTTP-to-PostgreSQL example against a running authenticated server:

LOOMABASE_JWT_SECRET='replace-with-at-least-32-bytes' \
  cargo run --features server --example http_offline_roundtrip

LOOMABASE_JWT_SECRET='replace-with-at-least-32-bytes' \
  cargo run --features server --example http_partial_replica

Merge an authenticated payload on PostgreSQL:

use loomabase::Result;
use loomabase::crdt::SyncPayload;
use loomabase::server::merge_crdt_states;
use sqlx::PgPool;

async fn synchronize(
    pool: &PgPool,
    payload: SyncPayload,
    authenticated_device_id: &str,
) -> Result<SyncPayload> {
    let mut tx = pool.begin().await?;
    let response = merge_crdt_states(
        &mut tx,
        payload,
        authenticated_device_id,
        "authenticated-tenant",
        &loomabase::schema::todos_table(),
    )
    .await?;
    tx.commit().await?;
    Ok(response)
}

The API layer must authenticate the device and pass the authenticated tenant to the merge. The merge establishes the transaction-scoped PostgreSQL RLS context.

Arbitrary Contracts

todos is just the canonical contract. A TableDef declares any single table; the SQLite and PostgreSQL schema, change-capture triggers, validation, value codec, and materialization are all generated from it. The generic row API (insert, set, get_cell, delete, restore) then synchronizes that contract end to end.

use std::collections::BTreeMap;
use loomabase::Result;
use loomabase::client::SqliteClient;
use loomabase::crdt::CrdtValue;
use loomabase::schema::{ColumnDef, ColumnType, TableDef};

#[tokio::main]
async fn main() -> Result<()> {
    let notes = TableDef::new(
        "notes",
        vec![
            ColumnDef::new("body", ColumnType::Text),
            ColumnDef::new("priority", ColumnType::Integer),
        ],
    )?;
    let client = SqliteClient::open_with("edge.db", "device-01", notes).await?;
    client
        .insert(
            "note-1".into(),
            BTreeMap::from([
                ("body".into(), CrdtValue::Text("buy milk".into())),
                ("priority".into(), CrdtValue::Integer(2)),
            ]),
        )
        .await?;
    Ok(())
}

Supported column domains are Text, Integer, Real, and Boolean. Row lifecycle (deleted) is a reserved liveness register managed through delete and restore.

Contracts evolve safely: opening a client or initializing the server with a contract that adds columns runs an automatic additive migration (ALTER TABLE … ADD COLUMN plus trigger regeneration on SQLite) on the existing database. Destructive changes — a removed or retyped column — are rejected rather than applied. Because each replica's schema_fingerprint changes with the contract, client and server only resume syncing once both sides have migrated.

Running the Server

A reference HTTP server lives behind the optional server feature, keeping the core library dependency-light:

DATABASE_URL=postgres://postgres:postgres@localhost:5432/loomabase \
  cargo run --features server --bin loomabase-server

It is configured by environment variables: LOOMABASE_BIND (default 127.0.0.1:8080), LOOMABASE_JWT_PUBLIC_KEY, LOOMABASE_JWT_SECRET, LOOMABASE_JWT_AUDIENCE, LOOMABASE_JWT_ISSUER, LOOMABASE_SUPABASE_URL, LOOMABASE_SUPABASE_JWKS, LOOMABASE_JWKS_REFRESH_SECS, LOOMABASE_SUPABASE_TENANT_CLAIM, LOOMABASE_SUPABASE_TABLES_CLAIM, LOOMABASE_BODY_LIMIT_BYTES, LOOMABASE_REQUEST_TIMEOUT_SECS, LOOMABASE_MAX_CONCURRENT_REQUESTS, LOOMABASE_STATEMENT_TIMEOUT_SECS, LOOMABASE_LOCK_TIMEOUT_SECS, LOOMABASE_DB_MAX_CONNECTIONS, LOOMABASE_DB_MIN_CONNECTIONS, LOOMABASE_DB_ACQUIRE_TIMEOUT_SECS, LOOMABASE_DB_TRANSACTION_POOLER, and RUST_LOG (structured tracing output, default info). It exposes GET /health, GET /metrics (Prometheus), and POST /sync. It logs each request and merge outcome, shuts down gracefully on SIGINT/SIGTERM, and warns at startup if connected as a PostgreSQL superuser.

The sync handler authenticates the request, runs the transactional, tenant-scoped merge_crdt_states, and returns the server response as JSON. It selects Supabase asymmetric JWKS when LOOMABASE_SUPABASE_URL is set, otherwise an RS256 public-key verifier or HS256 shared-secret verifier. Without a configured verifier, startup fails closed. The insecure HeaderDeviceAuthenticator stub can only be enabled explicitly with LOOMABASE_ALLOW_INSECURE_HEADERS=true for development. Either way the authenticated tenant_id — never the payload — is the isolation boundary, and every server row and clock is keyed by it. Provide your own DeviceAuthenticator implementation for other token schemes.

Supabase PostgreSQL and Supabase Auth are supported directly, including rotatable asymmetric JWKS and Supavisor transaction mode. See the Supabase integration guide.

Apply schema changes with a migration role, then run the service with a non-superuser DML-only role:

DATABASE_URL=postgres://migration-role:...@db/loomabase \
LOOMABASE_MIGRATE_ONLY=true \
  cargo run --features server --bin loomabase-server

DATABASE_URL=postgres://runtime-role:...@db/loomabase \
LOOMABASE_SKIP_SCHEMA_INIT=true \
LOOMABASE_JWT_PUBLIC_KEY='...' \
  cargo run --features server --bin loomabase-server

The runtime role needs DML rights on Loomabase tables plus USAGE, SELECT on loomabase_seq; it must not be a PostgreSQL superuser.

Language SDKs

The loomabase-ffi crate exposes the CRDT protocol core over a small, stable C ABI (see loomabase-ffi/include/loomabase.h) as the foundation for Swift, Kotlin, C, or Python (cffi) SDKs. Handles serialize concurrent merges, expose an ABI version, and provide thread-local error diagnostics. A caller JSON-encodes a SyncPayload, merges it for a device, and receives the JSON server response; storage and transport stay on the host side. It is a separate workspace crate because the C ABI requires unsafe, which the core crate forbids.

cargo build -p loomabase-ffi --release   # builds the cdylib

The contract code generator emits typed Swift, Kotlin, TypeScript, and Dart models plus a transport interface:

cargo run --example generate_sdks

Conflict decisions can be explained through explain::explain_lww. The replica module implements revisioned authoritative membership, safe local-only eviction, and validated query planning. The deterministic network simulator can produce a visual report:

cargo run --example simulation_report
cargo run --release --bin loomabase-bench

Development and Verification

Run the local quality gate:

cargo fmt --check
cargo clippy --all-targets --all-features -- -D warnings
cargo test --all-targets

Run the PostgreSQL integration test:

docker run --rm --name loomabase-postgres \
  -e POSTGRES_PASSWORD=postgres \
  -e POSTGRES_DB=loomabase \
  -p 5432:5432 postgres:17-alpine

LOOMABASE_TEST_DATABASE_URL=postgres://postgres:postgres@localhost:5432/loomabase \
  cargo test --test postgres_integration

CI runs all tests against PostgreSQL, Clippy with warnings denied, formatting, cargo audit, and cargo deny; scheduled jobs run the ignored soak target and fuzz both base-sync and partial-replica protocol inputs. Use ops/k6-sync.js and the public benchmark methodology for reproducible load tests.

Security & Best Practices

Read SECURITY.md before production deployment. Loomabase treats every sync payload as untrusted input. The CRDT merge is deterministic and idempotent, but it is not an authorization system: a valid authenticated writer can still submit a valid newer value. Use Loomabase together with application authorization, schema contracts, validation, rate limits, and audit logging.

Malicious or Malformed CRDT Updates

Loomabase rejects malformed or unsafe payloads before mutation:

  • protocol versions must be supported during the rolling-upgrade window;
  • schema fingerprints must match the server contract;
  • table and column names come from validated TableDef contracts, never from payload-controlled SQL identifiers;
  • values are type-checked against the contract and written with SQL parameters;
  • row counts, cell counts, identifier lengths, value sizes, response sizes, finite numbers, cursor capabilities, and Lamport clock advances are bounded;
  • the authenticated device_id must match every submitted mutation, preventing device-attribution spoofing;
  • the authenticated tenant_id, not any payload field, scopes the PostgreSQL transaction and Row-Level Security context.

Once a payload is valid and authorized, conflicts are resolved per column with the documented LWW order: (lamport_clock, device_id). Older writes and duplicate deliveries are harmless. Equal versions with different values are rejected because one CRDT version cannot safely identify two different states. For user-facing diagnostics, expose explain::explain_lww so operators can see which value won and why.

Data Validation Before Sync

Validate data at the application boundary before it reaches the sync engine. Recommended checks:

  • enforce per-user and per-tenant write permissions before calling merge_crdt_states;
  • reject fields the authenticated user cannot edit, even if the table contract contains them;
  • validate domain rules such as length, enum membership, numeric ranges, foreign-key ownership, and state transitions;
  • keep secrets, access tokens, API keys, and password material out of synchronized tables;
  • use PostgreSQL constraints and forced RLS as defense in depth, not as a replacement for API-layer authorization;
  • store audit events for security-relevant writes and conflict decisions.

For Supabase deployments, keep tenant and table authorization in trusted app_metadata claims. Do not rely on user-editable user_metadata for sync authorization.

Sync Endpoint Hardening

Expose /sync and /sync/partial only over TLS and require a signed Authorization: Bearer token. In production, put the reference server behind a gateway or load balancer that applies body-size, request-rate, connection, and IP reputation limits in addition to Loomabase's built-in request, body, concurrency, statement, lock, and pool limits.

For browser clients, configure CORS as an allowlist:

Access-Control-Allow-Origin: https://app.example.com
Access-Control-Allow-Methods: POST, OPTIONS
Access-Control-Allow-Headers: Authorization, Content-Type
Access-Control-Max-Age: 600
Vary: Origin

Avoid Access-Control-Allow-Origin: * on authenticated sync endpoints, and do not combine wildcard origins with credentials. If cookies are used instead of bearer tokens, require SameSite=Lax or SameSite=Strict, Secure, and CSRF protection.

Content Security Policy belongs on the browser application and any HTML served by your gateway. A sync endpoint that returns JSON does not need to execute script, but the web app should restrict where it can send sync traffic:

Content-Security-Policy: default-src 'self'; connect-src 'self' https://api.example.com https://*.supabase.co; object-src 'none'; base-uri 'none'; frame-ancestors 'none'

Also set Content-Type: application/json, X-Content-Type-Options: nosniff, Cache-Control: no-store for sync responses, Referrer-Policy: no-referrer, and HSTS at the TLS termination layer.

Roadmap

  • Stateless signed cursors or compact summaries for deployments that do not want server-side opaque cursor capabilities
  • Schema registry and generated typed table adapters
  • Broader protocol fuzzing and fault injection
  • Kubernetes/Terraform deployment modules
  • Stable, versioned wire protocol
