EtwSuite

EtwSuite is an ETW inspection suite inspired by EtwExplorer built as a Windows App with the goal of being a one stop shop for ETW provider browsing, live event collection, recording, filtering, and offline inspection easier to work with from one local desktop tool.

Current Features

[!IMPORTANT]

ETW metadata is often incomplete, provider specific, version dependent, or access restricted. EtwSuite won't be able to load all providers and will show an appropriate error when metadata is not available.

  • List registered ETW providers.
  • Search providers by name or GUID, including wildcard matching.
  • Inspect provider GUIDs and available event schema metadata.
  • Consume live ETW events from a selected provider.
  • Enable providers by GUID or name with explicit level and keyword masks.
  • View live events with provider, event name, ID, version, opcode, level, process, thread, and payload fields.
  • Filter live and recorded events with basic text/wildcard search.
  • Filter events with either basic wildcard or a SQL style expression parser.
  • Record consumed sessions to native .etl files.
  • Export captured event rows to JSON and CSV.
  • Open supported recordings: Any .etl, exported .json and .csv.
  • Save, load, and delete session templates in a local SQLite database.
  • Open a provider directly from the provider list in the consuming window.
  • Intel x64 and ARM64 compatibility.

Filtering

The event filter supports two modes:

  • Basic: case-insensitive text search with * and ? wildcard support.
  • SQL: a safe in-process expression parser. EtwSuite does not execute SQL against a database and does not allow function calls or arbitrary member access.

Example SQL filters:

event_id = 1
process_name LIKE 'powershell%'
payload.ImageName LIKE '*cmd.exe'
WHERE provider LIKE 'Microsoft-Windows-*' AND pid = 4242

See the help page on the application for the full field list and syntax.

Recordings

EtwSuite can currently open:

  • .etl: native ETW trace files read with TraceEvent.
  • .json: JSON files exported by EtwSuite.
  • .csv: CSV files exported by EtwSuite.

.evtx and other file types are not supported yet. ETL payload decoding is best effort because provider metadata may not be present on the machine reading the file.

See the help page on the application for the current recording behavior.

Basic Usage

  1. Install or build EtwSuite and its dependencies.
  2. Use List Providers to find a provider by name or GUID.
  3. Open Consume Provider, select a provider, choose level/keyword options, and start consuming events.
  4. Use Record ETL if you want a native ETW recording.
  5. Use Open Recording to inspect .etl, .json, or .csv files later.
  6. Use Saved Sessions to persist provider and filter combinations in SQLite.

Setup

Installation

For installation, download the latest release and install the MSI for your architecture.

Build From Source

Requirements

  • Windows 10 1809 or newer.
  • Visual Studio 2022 or newer with .NET desktop development support.
  • .NET 8 SDK.
  • Windows App SDK build support.
  • The listed dependencies.

Dependencies

Some live ETW providers require administrator privileges or special system permissions (e.g. Microsoft-Windows-Threat-Intelligence). Basic provider browsing, saved sessions, and supported offline recording inspection should not require elevation.

Build Commands

dotnet build EtwSuite.sln

Release build:

dotnet build EtwSuite.sln -c Release

Build MSI installers:

dotnet build installer\EtwSuite.Installer\EtwSuite.Installer.wixproj -c Release -p:Platform=x64 -p:AcceptEula=wix7
dotnet build installer\EtwSuite.Installer\EtwSuite.Installer.wixproj -c Release -p:Platform=ARM64 -p:AcceptEula=wix7

Only pass AcceptEula=wix7 after confirming the WiX Toolset OSMF terms apply appropriately for your use.

The installer version follows major.minor.patch. Bump it for every release so Windows Installer performs a real major upgrade. Either edit MajorVersion, MinorVersion, and PatchVersion in installer/EtwSuite.Installer/EtwSuite.Installer.wixproj or override on the command line:

dotnet build installer\EtwSuite.Installer\EtwSuite.Installer.wixproj -c Release -p:Platform=x64 -p:AcceptEula=wix7 -p:PatchVersion=2

If ICE validation fails because the build environment cannot access the Windows Installer service, add -p:SuppressValidation=true.

Test

dotnet test EtwSuite.sln

AI Usage

EtwSuite was built by myself with the help of Codex and Github Copilot. With that being said, all the functionality was validated and the AI generated code got reviewed (and modified) by me. I have appended an AGENTS.md file and .agents folder to the repo with the instructions for better project understanding.

With that being said, any low quality code PRs will be closed and ignored, and repeated low quality contributions may lead to a block.
