An agentic skill that gives an LLM access to Ghidra so it can perform reverse engineering tasks autonomously: decompile functions, trace call graphs, rename and annotate symbols, define data structures, diff binary versions, and more — all without human intervention.

ghidra-rpc runs Ghidra as a persistent background daemon and exposes its capabilities through a CLI that returns structured JSON. Any AI coding assistant that can run shell commands (pi, Claude Code, Cursor, etc.) can drive a full RE session by issuing commands and reasoning over the results.

Developed at Cellebrite Labs.

What the AI Can Do

Area Capabilities
Understand code Decompile functions to pseudo-C, disassemble, inspect CFG and P-code
Navigate Trace callers/callees, search strings and byte patterns, find cross-references
Annotate Rename functions and symbols, add comments, set bookmarks and tags
Type recovery Define structs/unions/enums, retype variables, set function signatures
Patch Assemble instructions (SLEIGH), write raw bytes, override flow types
Diff binaries Version-track two builds, diff changed functions, match functions via BSim

Quick Start

# Prerequisites: Ghidra 11+, Python 3.11+, Java 17+, uv
export GHIDRA_INSTALL_DIR=/opt/ghidra_12.0
uv tool install /path/to/ghidra-rpc

Once installed, tell your AI assistant to start a session:

"Load /usr/bin/ls into Ghidra and find any unsafe string operations."

For manual use or debugging:

# Start the daemon (use --detach for background)
ghidra-rpc start --project /tmp/work.gpr --headless

export GHIDRA_RPC_PROJECT=/tmp/work.gpr
ghidra-rpc load /usr/bin/ls
ghidra-rpc decompile ls main
ghidra-rpc xrefs-to ls strcmp
ghidra-rpc rename-function ls FUN_00401234 parse_args

To see all running daemon instances and attach to an existing one:

ghidra-rpc list-instances
# {"ok": true, "result": {"instances": [{"project": "/tmp/work.gpr", "mode": "headless", "pid": 84712, ...}], "count": 1}}

export GHIDRA_RPC_PROJECT=/tmp/work.gpr
ghidra-rpc list-binaries   # attach to the existing session

See docs/install.md for prerequisites and docs/quickstart.md for a full walkthrough.

How It Works

┌─────────────┐      Unix Socket       ┌──────────────────────────┐
│  LLM agent  │  ──── JSON/newline ──→ │  ghidra-rpc daemon       │
│  (via CLI)  │  ←── JSON/newline ───  │  (PyGhidra + Ghidra JVM) │
└─────────────┘                        └──────────────────────────┘

The daemon runs Ghidra in-process via PyGhidra. Ghidra loads the binary once and stays warm between commands — no re-analysis on every invocation. All changes (renames, comments, type definitions, patches) are saved to the Ghidra project after every command and remain visible when you open the project in the Ghidra GUI.

Runtime Paths

All paths use an 8-character hash derived from the absolute .gpr project path, so each project gets its own deterministic socket and session file with no collisions.

Path Purpose
/tmp/ghidra-rpc-<hash>.sock Unix socket for a running daemon
/tmp/ghidra-rpc-<hash>.log Background daemon log (--detach mode)
<project-dir>/.ghidra-rpc-<hash>.json Per-project session file (default, alongside .gpr)
$GHIDRA_RPC_STATE_DIR/<hash>.json Per-project session file when override is set
~/Library/Application Support/ghidra-rpc/sessions.json Global session registry (macOS)
~/.local/state/ghidra-rpc/sessions.json Global session registry (Linux)
$XDG_STATE_HOME/ghidra-rpc/sessions.json Global session registry (Linux, if $XDG_STATE_HOME set)
$GHIDRA_RPC_STATE_DIR/sessions.json Global session registry when override is set

$GHIDRA_RPC_STATE_DIR is a single knob that redirects both per-project session files and the global registry to a custom directory — useful in sandboxed or CI environments.

The global session registry is maintained automatically: start adds an entry, stop removes it, and list-instances prunes any entries whose socket file has disappeared (e.g. after a crash).
