Reverse Engineering eXecution Skill
Find the defects in a compiled binary — and prove them.
Seven subagents, one evidence tree, and a pinned toolchain so two runs are comparable.
Ghidra · radare2 · rizin · qemu-user · angr · z3 · AFL++ · valgrind · capa · Unicorn · Triton · Frida · semgrep · clang · Python · Nix
all pinned, all reproducible
1. Install the Claude skill
1 · Claude Code — skip if you already have it.
curl -fsSL https://claude.ai/install.sh | bash
2 · REx@Skill — 1 skill, 12 references, 7 subagents, 33 scripts.
curl -fsSL https://raw.githubusercontent.com/tihanyin/REx-skill/main/install.sh | sh
3 · analyse a binary.
claude
> /re-analyze path/to/binary # one target
> /re-analyze path/to/directory/ # a whole corpus, evidence gathered in parallel
install.sh writes only to ~/.claude/ — the skill and its 33 pipeline scripts, the 7 agents, /re-analyze.It never installs Claude Code for you; it backs up anything it would overwrite, and
--uninstall removes it cleanly.
Prefer to clone? · or install somewhere else, or remove it
git clone https://github.com/tihanyin/REx-skill && cd REx-skill
./install.sh # into ~/.claude
./install.sh --prefix ~/.config/claude # somewhere else
./install.sh --uninstall # take it back out
2. Tools used by this skill
Ghidra · radare2 · rizin · qemu-user · angr · z3 · AFL++ · valgrind · capa
Unicorn · Triton · Frida · semgrep · clang · Python · Nix · Linux · Claude
REx@Skill uses state-of-the-art tools collected by reverse-engineering experts. Each one is in the set because it earns its place on known benchmarks and real binary-analysis challenges — not because it was convenient to install. Nothing here is reimplemented; the skill's own job is knowing which tool answers the question in front of it, and what its answer is worth.
| Tool | What it does |
|---|---|
| Ghidra | turns a compiled binary back into readable C |
| radare2 / rizin | a second decompiler, used to cross-check the first |
| qemu-user | runs ARM, MIPS, PowerPC and RISC-V binaries on a normal x86 machine |
| z3 | a maths solver — proves whether an index can leave its buffer, or a divisor can be zero |
| angr | works out what input would reach a given line of code |
| AFL++ | throws millions of generated inputs at the program to make it crash |
| valgrind | catches memory bugs that otherwise cause no visible error |
| libdislocator | makes reading one byte past a buffer crash straight away |
| capa | lists what the binary can do: encrypt, open sockets, inject into processes |
| floss | finds hidden text that plain strings misses |
| Unicorn | runs a single function on inputs you choose, without running the program |
| Triton | follows where attacker-controlled data travels during a run |
| Frida | watches and changes a program while it is running |
| semgrep / cppcheck | scan the decompiled C for known bad patterns |
| pwntools | the helper library for offsets, ELF parsing and exploit work |
These are the exact versions it was built and measured with:
Ghidra 12.1.2 · radare2 6.2.0 · rizin 0.9.1 · qemu-user 11.1.0 + 9 cross-sysroots · angr 9.2.154 · z3 4.16.0 · AFL++ 5.00c · valgrind 3.27.1 · capa 9.4.0 · Unicorn 2.1.4 · Triton 3.7.0 · Frida 17.17.0 · clang 21.1.8 · semgrep 1.172.0 · floss 3.1.1 · yara 4.5.7 · binwalk 3.1.0 · pwntools 4.15.0 · cppcheck 2.21.1
Every one is optional. scripts/capabilities.sh reports what this machine has,
each script names the tool it cannot find, and a missing tool narrows the analysis
into limitations rather than failing silently.
Don't have them? The DEVSHELL installs all of it, pinned
Three commands and every tool above is on your PATH, at exactly these versions —
nothing to hunt down, nothing left half-configured.
git clone https://github.com/tihanyin/REx-skill 2>/dev/null || git -C REx-skill pull
cd REx-skill
curl --proto '=https' --tlsv1.2 -sSf -L https://install.determinate.systems/nix | sh -s -- install --no-confirm
nix develop ./devshell
scripts/capabilities.sh
| 0 | clones the repo, or updates it if you already have one — the one-line skill installer above does not leave a clone behind, it works from a temporary checkout and removes it, so the toolchain and the scripts need one of their own |
| 1 | installs Nix, the package manager that does the pinning — then open a new terminal. Already have Nix? Skip it. Re-running the installer over an existing install fails with Found existing plan in /nix/receipt.json, which is it declining to touch what you already have, not an error to fix |
| 2 | enters the shell, from the repo root so scripts/ stays on hand. First time downloads a lot; every time after is seconds |
| 3 | confirms it: ghidra pyghidra r2 rizin, qemu-user architectures: 7, angr, z3, afl — instead of the MISS lines a bare machine gives |
exit puts your PATH back exactly as it was. Tested on Ubuntu 22.04.5 LTS
(x86-64), Determinate Nix 3.22.4.
Why pin the toolchain at all?
- Comparable runs. The decompiler's output is the analyst's input. Two people on two Ghidra versions are not doing the same experiment, and neither can check the other's result.
- Nothing installed on your machine. Nix keeps every package under a hash of
what built it, so entering the shell changes
PATHand nothing else. Leave the shell and your system is exactly as it was. - It still works in five years. Three pinned revisions rebuild the whole toolchain, which is what makes a published number re-checkable later.
Three revisions rebuild the entire toolchain, on any machine, at any point in the future:
nixpkgs ffb3c9b700e759be2ef13237c9d8f953b32a1e46
nixpkgs-angr ac62194c3917d5f474c1a844b6fd6da2db95077d
capa-rules v9.4.0
devshell/flake.lock is the authority; devshell/DEVSHELL.md
lists every tool with its version and what it is for.
3. REx@Skill methodology and architecture
REx@Skill is a method for deciding whether a binary has a defect — and proving it. Seven subagents run it, sharing one evidence directory.
One agent turns the binary into evidence: decompiled C, disassembly, strings, a map of which code reaches which, and what happens when you actually run it. Five agents then read that evidence at the same time, each hunting a different kind of defect, and none of them can see what the others found — five readers sharing one decompiler make the same mistakes, so keeping them apart buys five independent readings instead of one opinion repeated five times. A seventh reads the code first, then their findings, and decides which ones hold up.
Nothing is reported as a bug unless four things are named and located in the binary: where attacker-controlled data gets in (source), the operation it can break (sink), the check that should have stopped it (broken guard), and who is harmed (affected principal). Miss one and it goes out as an unproven lead, not a finding.
Every run delivers the same three things: the findings, what was ruled out and why, and what the host could not run.
The skillset has been tested across ten architectures — x86-64, i686, ARM, AArch64, MIPS and MIPS64 in both endiannesses, 32-bit PowerPC, RISC-V and Apple arm64 — on ELF, PE and Mach-O, firmware and raw blobs. Nothing caps it there: any architecture your decompiler can lift is in scope.
| Agent | Runs | In one line | |
|---|---|---|---|
| 01 | re-recon |
first, alone | Extracts the evidence. Does not hunt bugs — a confident finding here is the failure mode. |
| 02 | re-bughunt |
always | Builds the strongest honest case that a defect exists. Enumerates every sink. |
| 03 | re-safety |
always | Tries to prove it sound, and reports every obligation it cannot discharge. |
| 04 | re-arithmetic |
if it indexes or sizes | Size, index, width and signedness across call boundaries — discharged by a solver, not in someone's head. |
| 05 | re-lifecycle |
if it allocates | Allocation, free, ownership, init and error paths. The error path is the one nobody tested. |
| 06 | re-logic |
if it authenticates | Authorisation, state machines, crypto, validate-here-use-there. No signature to grep for. |
| 07 | re-reconcile |
last, alone | Reads the code before it reads anyone's conclusions, then adjudicates and reports. |
What you get back
One directory per binary, named <filename>-<first 8 hex of its SHA-256>:
results/
├── index.json every sha256 analysed -> its directory
└── httpd-4f2a9c1e/ <- "httpd", sha256 4f2a9c1e...
├── decomp/ decompiled C ├── reach/ source -> sink paths
├── disasm/ disassembly, real VAs ├── bounds/ arithmetic to discharge
├── meta/ function map + base ├── sanitize/ hostile-allocator runs
├── strings/ inventory, by family ├── fuzz/ coverage-guided search
├── dynamic/ crafted-input battery ├── quarantine/ text aimed at YOU
└── notes/ the threat model └── pipeline.json what ran, what did not
Why the hash is in the name. Two builds of a program share a filename but not a SHA-256, so evidence and binary cannot silently drift apart: recompile the target and you get a new directory rather than a polluted one.
pipeline_status.py audits that tree and reports which stages never ran — because a
stage that never ran leaves no error behind, only an absent directory, which reads
exactly like "ran, found nothing".
4. Tool inventory — which script calls what
Decompile and read
| Tool | Version | Used by | For |
|---|---|---|---|
| Ghidra | 12.1.2 | ghidra_export.py batch_decompile.sh decompile_addr.py |
the decompiler — the load-bearing tool |
| pyghidra | 3.1.0 | the same three | driving it headless |
| radare2 | 6.2.0 | run_tools.sh strings_report.py brief.py |
JSON out of every command |
| rizin | 0.9.1 | capabilities.sh preflight.sh |
a second decompiler — cross-check |
| binutils | 2.46 | triage.py inventory.py run_tools.sh |
readelf, objdump, nm, strings, size |
| file | 5.48 | every entry point | first command, every time |
Triage — what is it, what can it do
| Tool | Version | Used by | For |
|---|---|---|---|
| capa | 9.4.0 | run_tools.sh brief.py |
capabilities from rules, with addresses |
| floss | 3.1.1 | strings_report.py |
strings strings cannot see |
| yara | 4.5.7 | run_tools.sh analyze.sh |
packers, crypto constants, library versions |
| detect-it-easy | 3.21 | run_tools.sh |
packer and compiler identification |
| checksec | pwntools | triage.py brief.py |
NX / RELRO / canary / PIE |
Execute — the largest single lever
| Tool | Version | Used by | For |
|---|---|---|---|
| qemu-user | 11.1.0 | dynamic_probe.py quick_dynamic.sh |
run foreign-architecture binaries |
| 9 cross-sysroots | glibc | setup_sysroots.sh |
without them qemu cannot even load a foreign dynamic binary |
| gdb / ltrace / strace | 17.2 | capabilities.sh reports them |
traces; ltrace is the most under-used tool here |
On one measured comparison the same model scored roughly 3× the recall with execution available than without. This row is why the sysroots ship with the flake.
Make silent bugs loud
| Tool | Version | Used by | For |
|---|---|---|---|
| valgrind | 3.27.1 | sanitize_run.sh |
the closest thing to ASan for a binary you cannot rebuild |
| AFL++ | 5.00c | fuzz_target.sh quick_dynamic.sh |
coverage-guided fuzzing, QEMU mode |
| libdislocator | with AFL++ | sanitize_run.sh quick_dynamic.sh |
page-per-allocation — turns a silent OOB read into a fault |
| clang | 21.1.8 | triage.py |
-fsanitize=... on lifted code |
Solve and emulate
| Tool | Version | Used by | For |
|---|---|---|---|
| z3 | 4.16.0 | check_bound.py |
discharges a bounds claim — 9 modes plus a generic escape hatch |
| angr | 9.2.154 | symfn.py |
symbolic harness per function: hijack, OOB write, divide-by-zero |
| unicorn | 2.1.4 | emulate.py |
run ONE function in isolation on inputs you choose |
| triton | 3.7.0 | available | concolic execution and taint over a concrete trace |
| pwntools | 4.15.0 | brief.py run_tools.sh |
cyclic() offsets, ELF/GOT parsing |
Static analysis over decompiled C
| Tool | Version | Used by | For |
|---|---|---|---|
| cppcheck | 2.21.1 | run_tools.sh analyze.sh |
tolerates code that does not compile — decompiler output does not |
| semgrep | 1.172.0 | run_tools.sh analyze.sh |
pattern rules, no build needed |
| flawfinder | 2.0.20 | capabilities.sh |
lexical; a grep with opinions |
Also in the shell — firmware, formats, exploitability
binwalk 3.1.0 · unsquashfs · sasquatch · jefferson · ubi_reader ·
kaitai-struct-compiler 0.11 · tshark 4.6.8 · hexyl · pev 0.81 ·
osslsigncode · diffoscope 328 · patchelf 0.15.2 · ROPgadget 7.7 ·
one_gadget 1.9.0 · honggfuzz · radamsa 0.7 · bitwuzla 0.9.1 · rr 5.9.0 ·
bpftrace 0.26.0 · upx 5.2.0
Full inventory with every version: devshell/DEVSHELL.md
5. Use it with something other than Claude
general-skill/SKILL-RE.md is one self-contained file — 3 750 lines of plain
Markdown with name/description frontmatter. Everything the Claude bundle has,
in one piece: the same evidence standard, the same pipeline, the same rules about
fuzzing a foreign architecture. Clone the repo so scripts/ sits beside it, then:
| Runner | How |
|---|---|
| Codex | point AGENTS.md at it, or paste it as the system prompt |
| opencode | {"instructions": ["SKILL-RE.md"]} in opencode.json |
| Cursor / Windsurf | drop it in as a project rule |
| A plain API loop | it is just Markdown — prepend it |
| A human | it reads as a textbook; that was the point |
Why two forms? The Claude bundle is a 16 KB core plus twelve reference files loaded on demand — small context until a specific question needs a specific chapter. Only Claude Code follows those pointers, so every other runner gets the single file instead.
6. What is inside
.
├── claude-skill/ the Claude Code form
│ ├── skills/reverse-engineering/
│ │ ├── SKILL.md 16 KB core, loaded on every trigger
│ │ └── references/ 12 files, pulled in on demand
│ ├── agents/ 7 subagents
│ └── commands/ /re-analyze — orchestrates all three phases
│
├── general-skill/ the portable form
│ ├── SKILL-RE.md the whole methodology, one file, 32 sections
│ └── AGENTS.md points any agent at it
│
├── scripts/ 32 tools — the pipeline and its parts
├── devshell/ flake.nix + flake.lock + DEVSHELL.md
├── images/ logo and figures
└── install.sh one command into ~/.claude
The scripts that matter
capabilities.sh |
what this host can actually do — check before planning |
analyze.sh |
the whole pipeline in order, steps 0-5, then hands off |
batch_analyze.sh |
the same pipeline across a directory of targets |
pipeline_status.py |
audit an evidence tree: which stages ran, and what each absence costs |
overview.py |
the shape of a program: counts, call tree, sinks, sources |
brief.py |
every tool's output for one target, consolidated, gaps named |
fn.py |
read one function instead of the whole decompilation |
reach.py |
source → sink paths over the call graph |
bounds_worklist.py |
the arithmetic claims that need discharging, in three tiers |
check_bound.py |
discharge one with z3 — 9 modes plus a generic escape hatch |
symfn.py |
symbolic harness for one function |
emulate.py |
run one function in isolation on inputs you choose |
quick_dynamic.sh |
just run it: no input, then inputs that break most things |
fuzz_target.sh |
fuzzing aimed at the channel the program actually reads |
sanitize_run.sh |
hostile allocators — make a silent heap bug crash |
sanitize.py |
quarantine model-directed text before anything reads it |
7. Limitations
The skill runs anywhere Claude Code runs — Linux, macOS, WSL. It is markdown:
the core, 12 references, 7 subagents and /re-analyze. Nothing in it is
platform-specific, and the scripts are portable Python and bash. What varies is
the tools underneath them.
The DEVSHELL is built and tested on Linux — x86-64 (Ubuntu 22.04.5 LTS) and aarch64. macOS is where it thins out, because eleven of the tools do not exist on Darwin at all:
| absent on macOS | qemu-user · gdb · gef · ltrace · strace · valgrind · AFL++ · honggfuzz · frida · bpftrace · rr |
| also | capa's pinned build does not pass its own test suite on Darwin |
| and | argv fuzzing interposes __libc_start_main, which is glibc — there is no macOS equivalent |
qemu-user translates Linux syscalls, so it is Linux by definition, and the
nine cross-architecture sysroots go with it.
What that leaves on a Mac. Every static stage: Ghidra decompilation, radare2 and rizin, angr and z3, the static analysers, triage, strings and reachability. What you lose is execution — the dynamic probe, sanitizer runs, fuzzing, and any foreign-architecture binary. That is a real loss: a crash is the strongest evidence this methodology has, and nothing static replaces it.
Nothing pretends otherwise. scripts/capabilities.sh reports what the host
can actually do, scripts/pipeline_status.py marks the stage absent, and the
cost lands in the report's limitations. A stage that did not run is never
reported as a stage that ran and found nothing — see §9.1 of the skill.
In short: analyse on Linux. Read, plan and write the report anywhere.
Norbert Tihanyi · x.com/@TihanyiNorbert
a finding = source · sink · broken guard · affected principal.
anything less is a hypothesis.
Comments
