Version 1.0.7 — virtual WLED-style light effects for ordinary Home Assistant lights.

HA LightFX lets you build virtual room layouts, place Home Assistant light entities on a 0-100 grid, and run animated effects across them. It works with Zigbee, Z-Wave, Wi-Fi, Matter, Hue, ESPHome, or any other light that Home Assistant can control. No LED strip controller or WLED hardware is required.

HA LightFX

What You Get

  • A Home Assistant custom integration with persistent layout storage.
  • A visual config-flow editor for layouts, lights, profiles, and layout groups.
  • A bundled Lovelace custom card served by the integration at /ha_lightfx/ha-lightfx-card.js.
  • 16 Home Assistant services for automation, previewing, layout management, profiles, groups, and sequences.
  • 10 built-in effects: rainbow, chase, breathe, strobe, theater_chase, fire, color_cycle, sparkle, wave, twinkle.
  • Zone-aware effects, direction control, brightness/speed/transition controls, and optional audio-reactive brightness modulation.

Supported Effects

Effect Description Main Controls
rainbow Smooth hue sweep across lights based on virtual position. brightness, speed, direction
chase A single active light moves through the layout. color, brightness, speed, direction
breathe Slow fade in/out using the primary color. color, brightness, speed
strobe Alternating flash/on-off pulses. color, brightness, speed
theater_chase Alternating primary/secondary color chase. color, color2, brightness, speed, direction
fire Warm randomized flicker based on the primary color. color, brightness, speed
color_cycle Global hue transition across all mapped lights. brightness, speed
sparkle Random sparkle/twinkle flashes. brightness, speed
wave HSV wave across the virtual x/y layout. brightness, speed, direction
twinkle Random twinkling between two colors. color, color2, brightness, speed

Concepts

Layouts

A layout is a named virtual space, such as Living Room, Bedroom, or Downstairs. Layout IDs are generated from the name by lowercasing and replacing spaces with underscores. For example:

Name Layout ID
Living Room living_room
Kitchen kitchen
Downstairs Hall downstairs_hall

Light Positions

Each light has:

  • entity_id — the Home Assistant light entity, for example light.living_room_lamp.
  • x — horizontal position, 0-100.
  • y — vertical position, 0-100.
  • z — optional depth, 0-100. Current effects preserve and expose it; future effects can use it for 3D-style spatial animation.
  • zone — one of ceiling, wall, accent, floor, other.

Zones

Zones let you run different effects on different areas in one layout. Example: ceiling lights can run chase while wall lights run breathe.

Profiles

Profiles are named effect presets. They store an effect config so you can reuse it from automations or the visual editor.

Layout Groups

Layout groups let you run the same effect across several layouts at once, such as downstairs containing living_room, kitchen, and hallway.

Previous State Restore

When an effect starts, HA LightFX stores the previous state of every mapped light. ha_lightfx.stop_effect can restore those previous states with restore_previous: true.

Installation

  1. Open HACS → Integrations → ⋮ → Custom repositories.
  2. Add this repository URL:
    https://github.com/rusty4444/ha-lightfx
  3. Select category Integration.
  4. Click Add.
  5. Find HA LightFX in HACS and click Download.
  6. Restart Home Assistant.
  7. Go to Settings → Devices & Services → Add Integration and search for HA LightFX.

Manual Installation

  1. Download or clone this repository.
  2. Copy the integration folder:
    custom_components/ha_lightfx/
    into your Home Assistant config folder:
    /config/custom_components/ha_lightfx/
  3. Restart Home Assistant.
  4. Go to Settings → Devices & Services → Add Integration and search for HA LightFX.

Dashboard Resource

The Lovelace card is bundled inside the integration and served at:

/ha_lightfx/ha-lightfx-card.js

The Lovelace card is auto-registered as a dashboard resource when the integration starts. A hard browser refresh (Ctrl+Shift+R / Cmd+Shift+R) may be needed to pick up the card on first install.

If the card does not appear, verify the resource exists under Settings → Dashboards → Resources:

/ha_lightfx/ha-lightfx-card.js

with type JavaScript Module. Add it manually if needed.

Quick Start

  1. Install the integration and restart Home Assistant.
  2. Add the integration from Settings → Devices & Services → Add Integration → HA LightFX.
  3. Open the integration entry and click Configure.
  4. Choose Manage Layouts → Create Layout and create a layout, for example Living Room.
  5. Choose Manage Lights ��� Add Light.
  6. Pick a Home Assistant light entity.
  7. Set its x, y, optional z, and zone.
  8. Repeat for each light in the room.
  9. Add the dashboard card:
    type: custom:ha-lightfx-card
  10. Select the layout, choose an effect, and press Play.

Lovelace Card

The built-in card type is:

type: custom:ha-lightfx-card

The card auto-discovers layouts through the integration WebSocket API. No card-level YAML options are required for basic use.

The card provides:

  • Lovelace visual card editor via the dashboard UI.
  • Layout selector buttons.
  • Optional default layout selection.
  • 2D layout visualization.
  • Zone-colored light dots.
  • Optional drag-and-drop light repositioning.
  • Effect selector.
  • Primary and secondary color pickers.
  • Brightness and speed sliders.
  • Optional refresh button.
  • Play/Stop controls.

Lovelace Visual Editor Options

Open the dashboard editor, add Custom: HA LightFX, then configure the card from the visual editor. YAML editing is optional.

Option Type Default Description
title string HA LightFX Card header title.
default_layout string empty Layout ID to auto-select, for example living_room. Leave empty to select the first available layout.
show_layout_selector boolean true Show buttons for switching layouts. Disable this for a single-layout dashboard card.
show_zone_legend boolean true Show the zone color legend under the grid.
allow_drag boolean true Allow dragging light dots to update x/y positions.
show_refresh_button boolean true Show the header refresh button for reloading layouts.
confirm_stop boolean true Ask for confirmation before stopping and restoring lights.

Example YAML equivalent:

type: custom:ha-lightfx-card
title: Living Room FX
default_layout: living_room
show_layout_selector: false
show_zone_legend: true
allow_drag: true
show_refresh_button: true
confirm_stop: true

Visual Editor

Open Settings → Devices & Services → HA LightFX → Configure.

Available menus:

  • Manage Layouts — create and delete layouts.
  • Manage Lights — add, update, and remove mapped lights.
  • Manage Profiles — create and delete effect profiles.
  • Manage Groups — create and delete layout groups.

The visual editor is the recommended setup path. Services are available for automation and advanced users.

Services Reference

All services use the domain ha_lightfx.

Service Required Fields Optional Fields Response Support Description
create_layout name icon Optional Create a layout. With return_response: true, returns the generated layout_id.
remove_layout layout_id — No Delete a layout.
list_layouts — — Required Return all layouts, light counts, and status.
add_light layout_id, entity_id, x, y z, zone No Add or update a light's layout position.
remove_light layout_id, entity_id — No Remove a light from a layout.
start_effect layout_id effect, color, color2, brightness, speed, transition, direction, audio_entity_id, effect_per_zone No Start an effect loop.
stop_effect layout_id restore_previous No Stop an effect and optionally restore previous light states.
preview_effect layout_id effect, params Optional Compute one preview frame without starting an effect.
create_profile name config No Save an effect profile.
delete_profile profile_id — No Delete a profile.
list_profiles — — Required Return all saved profiles.
create_group group_id, layout_ids — No Create or replace a layout group.
delete_group group_id — No Delete a layout group.
list_groups — — Required Return all layout groups.
start_sequence layout_id, sequence effect, brightness No Run timed effect steps on one layout.
start_layout_group group_id effect, color, color2, brightness, speed, transition, direction No Start the same effect across a layout group.

Common Field Values

Field Accepted Values
effect rainbow, chase, breathe, strobe, theater_chase, fire, color_cycle, sparkle, wave, twinkle
color, color2 RGB list such as [255, 0, 0] or a hex string where supported by service calls.
brightness Integer 0-100.
speed Integer 1-100.
transition Seconds, 0.1-5.0.
direction forward, reverse, bounce.
zone ceiling, wall, accent, floor, other.

Service Examples

Create a Layout and Get the ID

service: ha_lightfx.create_layout
return_response: true
data:
  name: "Living Room"
  icon: mdi:sofa

Response:

layout_id: living_room

Add Lights to a Layout

service: ha_lightfx.add_light
data:
  layout_id: living_room
  entity_id: light.living_room_ceiling
  x: 50
  y: 20
  z: 10
  zone: ceiling

service: ha_lightfx.add_light
data:
  layout_id: living_room
  entity_id: light.floor_lamp
  x: 20
  y: 80
  z: 0
  zone: accent

Start a Basic Effect

service: ha_lightfx.start_effect
data:
  layout_id: living_room
  effect: rainbow
  brightness: 60
  speed: 40
  transition: 0.5
  direction: forward

Start a Two-Color Effect

service: ha_lightfx.start_effect
data:
  layout_id: living_room
  effect: theater_chase
  color: [255, 0, 0]
  color2: [0, 0, 255]
  brightness: 70
  speed: 50

Stop and Restore Previous Light States

service: ha_lightfx.stop_effect
data:
  layout_id: living_room
  restore_previous: true

Preview One Frame

service: ha_lightfx.preview_effect
return_response: true
data:
  layout_id: living_room
  effect: fire
  params:
    color: [255, 100, 0]
    brightness: 70
    speed: 40

Zone-Aware Effects

service: ha_lightfx.start_effect
data:
  layout_id: living_room
  brightness: 60
  speed: 45
  effect_per_zone:
    ceiling: chase
    wall: breathe
    accent: sparkle
    floor: wave

Audio-Reactive Effect

audio_entity_id can point at a media_player. HA LightFX uses the player's volume_level attribute to modulate effect brightness.

service: ha_lightfx.start_effect
data:
  layout_id: living_room
  effect: fire
  color: [255, 100, 0]
  brightness: 70
  audio_entity_id: media_player.living_room

Create a Profile

service: ha_lightfx.create_profile
data:
  name: "Warm Fire"
  config:
    effect: fire
    color: [255, 120, 20]
    brightness: 55
    speed: 35

Create a Layout Group

service: ha_lightfx.create_group
data:
  group_id: downstairs
  layout_ids:
    - living_room
    - kitchen
    - hallway

Start an Effect Across a Group

service: ha_lightfx.start_layout_group
data:
  group_id: downstairs
  effect: rainbow
  brightness: 50
  speed: 40

Run a Sequence

service: ha_lightfx.start_sequence
data:
  layout_id: living_room
  brightness: 80
  sequence:
    - effect: rainbow
      duration_seconds: 30
    - effect: chase
      duration_seconds: 15
      speed: 60
    - effect: strobe
      duration_seconds: 10
      brightness: 100

Automation Examples

Motion-Triggered Rainbow After Sunset

alias: "Rainbow on Arrival"
trigger:
  - platform: state
    entity_id: binary_sensor.motion_living_room
    to: "on"
condition:
  - condition: sun
    after: sunset
action:
  - service: ha_lightfx.start_effect
    data:
      layout_id: living_room
      effect: rainbow
      brightness: 40
      speed: 30
  - delay:
      minutes: 5
  - service: ha_lightfx.stop_effect
    data:
      layout_id: living_room
      restore_previous: true

Bedtime Breathe

alias: "Bedtime Breathe"
trigger:
  - platform: time
    at: "22:00:00"
action:
  - service: ha_lightfx.start_effect
    data:
      layout_id: bedroom
      effect: breathe
      color: [255, 50, 50]
      brightness: 20
      speed: 20

Doorbell Party Sequence

alias: "Doorbell Party Sequence"
trigger:
  - platform: state
    entity_id: binary_sensor.doorbell
    to: "on"
action:
  - service: ha_lightfx.start_sequence
    data:
      layout_id: living_room
      brightness: 80
      sequence:
        - effect: rainbow
          duration_seconds: 30
        - effect: chase
          duration_seconds: 15
          speed: 60
        - effect: strobe
          duration_seconds: 10
          brightness: 100

Troubleshooting

The card is not available in the dashboard card picker

  • Confirm the integration is installed and Home Assistant has been restarted.
  • Confirm the dashboard resource exists:
    /ha_lightfx/ha-lightfx-card.js
  • Resource type must be JavaScript Module.
  • Hard refresh the browser: Ctrl+Shift+R / Cmd+Shift+R.
  • Check browser dev tools for failed requests to /ha_lightfx/ha-lightfx-card.js.

A layout has no lights

  • Open Configure → Manage Lights and add at least one light.
  • Or call ha_lightfx.add_light with the correct layout_id and entity_id.
  • Use ha_lightfx.list_layouts with return_response: true to inspect current layout state.

Effects start but lights do not visibly change

  • Confirm the mapped entities are real light entities and are available in Home Assistant.
  • Some lights may not support RGB color; try effects that rely mostly on brightness or use supported color modes.
  • Try lower transition and higher brightness.
  • Check Home Assistant logs for ha_lightfx warnings.

Effects stop but lights do not restore

  • Use:
    service: ha_lightfx.stop_effect
data:
  layout_id: living_room
  restore_previous: true
  • Restore only applies to lights that were part of the layout when the effect started.

A grouped layout was deleted

start_layout_group skips stale/missing layout IDs and logs a warning. Recreate the missing layout or update the group with create_group using the current list of layout IDs.

Storage and Data

HA LightFX stores layouts, lights, profiles, and groups in Home Assistant storage under the integration's storage key. Data persists across Home Assistant restarts.

Stored data includes:

  • Layout names and icons.
  • Light entity IDs and x/y/z/zone positions.
  • Effect profiles.
  • Layout groups.

Development

Repository structure:

custom_components/ha_lightfx/
├── __init__.py             # Integration setup, service registration, WebSocket API, frontend serving
├── config_flow.py          # Initial setup and visual configuration editor
├── const.py                # Constants, service names, effects, storage version
├── lightfx_engine.py       # Effect engine and persistence model
├── manifest.json           # Home Assistant manifest
├── services.yaml           # Service definitions shown in Developer Tools
├── strings.json            # Config-flow UI strings
├── translations/
│   └── en.json             # English translations
├── brand/
│   ├── icon.png
│   ├── [email protected]
│   ├── logo.png
│   └── [email protected]
└── www/
    └── ha-lightfx-card.js  # Bundled, browser-loadable Lovelace custom card

frontend/
└── ha-lightfx-card.js      # Source for the card/editor before bundling

The committed custom_components/ha_lightfx/www/ha-lightfx-card.js file is the browser-loadable bundle used by Home Assistant. Edit frontend/ha-lightfx-card.js, then rebuild the bundle:

npm install
npm run build:card

Useful validation commands:

python3 -m py_compile custom_components/ha_lightfx/*.py
python3 -m json.tool custom_components/ha_lightfx/manifest.json >/dev/null
python3 -m json.tool hacs.json >/dev/null
python3 -m json.tool custom_components/ha_lightfx/strings.json >/dev/null
python3 -m json.tool custom_components/ha_lightfx/translations/en.json >/dev/null
ruby -e 'require "yaml"; YAML.load_file("custom_components/ha_lightfx/services.yaml")'
node --check frontend/ha-lightfx-card.js
node --check custom_components/ha_lightfx/www/ha-lightfx-card.js

AI Used in Development

This project used AI-assisted development for code review, bug fixing, documentation, and release tasks. Multi-model sequential reviews were run across the codebase to catch issues before release. All AI-generated changes were reviewed by a human before merging.
