air_tguserbot

πŸ‡·πŸ‡Ί Русская вСрсия

air_tguserbot is an AiR platform service for Telegram UserBots. It manages user Telegram sessions and provides an HTTP/WebSocket API, as well as a separate gRPC API for voice calls.

Important note

The project has been partially migrated to purego, but it is not yet a fully self-contained pure-Go application.

What has already been done:

  • the main Go binary is built with CGO_ENABLED=0;
  • voice-call library functions are called through ebitengine/purego, without a direct import "C";
  • the library is loaded at runtime through dlopen/dlsym.

What is not implemented yet:

  • there is no pure-Go implementation of the audio stack and WebRTC/Telegram voice calls;
  • voice calls use slim_libntgcalls.so, a precompiled C/C++ ntgcalls library;
  • this library requires glibc, libgcc, libstdc++, and libz, so the application runs in a glibc-based image (distroless/cc) rather than a fully static scratch/musl environment;
  • the purego adapter calls native functions using the Linux amd64 ABI and uses glibc's calloc/free to pass buffers compatible with the native library;
  • voice-call code is currently built only for linux/amd64 (//go:build amd64 && linux).

In other words, purego removes the CGO dependency from the Go-code build process, but it does not replace the native library itself. The regular UserBot features (HTTP, WebSocket, gRPC, Telegram API, MySQL, and Redis) work without a direct CGO dependency; the limitation primarily concerns voice calls. Running this functionality requires the slim_libntgcalls.so file shipped with the project and a glibc-compatible environment.

A complete pure-Go implementation of the project is possible. If you have the time and interest to help with this effort, your contribution would be greatly appreciated.

Features

  • connecting and managing Telegram UserBots;
  • starting, stopping, and restarting a user bot;
  • retrieving the bot name and checking service availability;
  • WebSocket connection for authentication and message exchange;
  • streaming contacts through WebSocket;
  • outgoing voice calls through Telegram;
  • server-streaming call events: transcription, AI response, errors, and termination;
  • state and configuration storage in MariaDB/MySQL;
  • restoring interaction state through Redis;
  • Prometheus metrics.

Architecture

air_tguserbot
β”œοΏ½οΏ½β”€ HTTP :8080
β”‚   β”œβ”€β”€ /tguser/available
β”‚   β”œβ”€β”€ /tguser/getname
β”‚   β”œβ”€β”€ /tguser/enable
β”‚   β”œβ”€β”€ /tguser/disable
β”‚   β”œβ”€β”€ /tguser/restart
β”‚   β”œβ”€β”€ /tguser/ws
β”‚   β”œβ”€β”€ /tguser/contacts/ws
β”‚   β”œβ”€β”€ /tguser/call/hangup
β”‚   └── /metrics
└── gRPC :9090
    └── calls.v1.Calls
        β”œβ”€β”€ StartOutgoingCall
        β”œβ”€β”€ SubscribeCallEvents
        └── HangupCall

The service receives Telegram UserBot configuration from air_orchestrator over gRPC. MariaDB/MySQL and, optionally, Redis are also used.

HTTP API

The complete route description is available in the OpenAPI specification.

All routes that operate on a user bot require the uid query parameter:

GET /tguser/getname?uid=42

Main routes:

Method Path Purpose
GET /tguser/available Check availability
GET /tguser/getname?uid=... Get the bot name
GET /tguser/enable?uid=... Start the bot
GET /tguser/disable?uid=... Stop the bot
GET /tguser/restart?uid=... Restart the bot
GET /tguser/ws?uid=... WebSocket authentication and messaging
GET /tguser/contacts/ws?uid=... WebSocket contacts stream
POST /tguser/call/hangup?userId=...&callId=... Hang up an active call
GET /metrics Prometheus metrics

WebSocket routes require the Upgrade: websocket header. If uid is missing, the server returns 400 with a JSON error.

gRPC Call API

The gRPC server listens on :9090 and implements the calls.v1.Calls service. Inside Docker, the service address is tguserbot_app:9090; locally, it is 127.0.0.1:9090.

Contract: calls.proto.

Typical flow:

StartOutgoingCall
        ↓ call_id
SubscribeCallEvents
        ↓ real-time events
HangupCall (if needed)
        ↓
CALL_ENDED

StartOutgoingCall accepts user_id, provider, and target, starts a call, and returns call_id. SubscribeCallEvents supports after_sequence to resume the stream after reconnecting. Audio is not transmitted over gRPC; it is processed inside the Telegram service.

Requirements

  • Go 1.25 or newer;
  • MariaDB/MySQL;
  • Redis β€” optional, but recommended for restoring state;
  • gRPC access to air_orchestrator;
  • a service key in the .service_key file.

Configuration

Main environment variables:

Variable Purpose
DB_HOST MariaDB/MySQL address
DB_NAME Database name
DB_USER Database user
DB_PASSWORD Database password
REDIS_ADDR Redis address; may be empty
REDIS_PASSWORD Redis password
REDIS_DB Redis database number
GRPC_CONFIG_HOST air_orchestrator gRPC address
SERVICE_KEY_FILE Path to the service key
REAL_URL Public service domain
LOG_LEVEL Logging level
GLOB_USER_MODEL_TTL User model TTL in minutes

Development and production values are specified in dev.yml and prod.yml. Do not add secrets to the repository.

Running

Run the application locally:

go run ./cmd

Run with Docker Compose:

docker compose -f dev.yml up -d --build

Production uses prod.yml:

docker compose -f prod.yml up -d --build

Before starting, the external networks specified in the Compose files must exist:

docker network create air_shared
docker network create monitoring_shared

Development

Check formatting and run tests:

gofmt -w ./cmd ./internal
go test ./...
  • air_orchestrator β€” AiR service configuration and coordination;
  • air-common β€” shared models, realtime providers, and infrastructure components;
  • air-logger β€” logging;
  • air_front β€” AiR platform user interface.
