beriberikix/network-provisioning-zephyr: an open-source tool on GitHub for self-hosters

A Zephyr RTOS port of Espressif's network provisioning protocol for Wi-Fi or Thread provisioning over Bluetooth LE, SoftAP or the device console.

It speaks the same protocomm wire protocol as ESP-IDF, so the stock Espressif provisioning apps work out of the box — no app changes, no custom client:

• ESP BLE Provisioning — Android (Play Store)
• ESP BLE Provisioning — iOS (App Store)
• ESP SoftAP Provisioning — Android / iOS

Wi-Fi credentials are stored through Zephyr's native wifi_credentials subsystem, and the connection is driven through the standard net_mgmt Wi-Fi management API.

Scope: Wi-Fi or Thread provisioning — mutually exclusive per build, like upstream (the CONFIG_NETWORK_PROV_NETWORK_TYPE choice) — over BLE, SoftAP (Wi-Fi only) and console transports, security schemes 0 (plaintext) and 1 (Curve25519 + AES-256-CTR + proof-of-possession). Security 2 (SRP6a) is not implemented.

How it maps to ESP-IDF

Architecture

The manager is transport-agnostic: it drives a struct network_prov_scheme vtable (start/stop) and never knows which transport is underneath. The transport feeds bytes to the protocomm core, which dispatches to endpoint handlers after the security layer has decrypted the request.

                    application
                        │  network_prov_mgr_* (include/network_provisioning/network_prov_mgr.h)
                        ▼
              ┌───────────────────────┐   lifecycle events
              │  manager / state machine │ ─────────────────► app event callback
              │  (network_prov_mgr.c)    │
              └───────────┬───────────────┘
                          │  struct network_prov_scheme vtable (start / stop)
              ┌───────────▼───────────────────────────────────┐
              │  transport scheme                               │
              │   BLE (GATT)  │  SoftAP (HTTP)  │  console (shell)│
              └───────────┬───────────────────────────────────┘
                          │  protocomm endpoints (proto-ver, prov-session, prov-config, …)
              ┌───────────▼───────────┐
              │  protocomm core         │ ── security 0 / 1 (handshake + encrypt/decrypt)
              │  (endpoint dispatch)    │
              └───────────┬───────────┘
                          │  endpoint handlers
              ┌───────────▼───────────────────────────┐
              │  Wi-Fi handlers: config / scan / ctrl   │
              └───────────┬───────────────────────────┘
                          │  net_mgmt  +  wifi_credentials
                          ▼
                Zephyr Wi-Fi  (or the fake_wifi backend under test)

Adding a transport means implementing one network_prov_scheme object; adding a device-specific feature means registering a custom endpoint. The protocol core and Wi-Fi handlers stay untouched in both cases.

Protocol surface

Over BLE, each protocomm endpoint is exposed as one GATT characteristic; the endpoint name is carried in the characteristic's 0x2901 (Characteristic User Description) descriptor, which is how the apps map names to characteristics. Over SoftAP, each endpoint is an HTTP POST URI (/proto-ver, /prov-session, …) served on the device-hosted access point at 192.168.4.1:80, with the session tracked by a session=<id> cookie. Over the console (CONFIG_NETWORK_PROV_CONSOLE), the same endpoints are reached through a single shell command — net_prov <endpoint> <session_id> <hex-request> — which prints the response as lowercase hex; this is the transport esp_prov --transport console speaks, useful for bring-up and debugging without BLE or a Wi-Fi AP.

A scan started with blocking = true (what the apps send) withholds its response until the scan completes, matching ESP-IDF; the apps query the scan status only once.

The .proto files under proto/ are taken verbatim from ESP-IDF (protocomm) and the network_provisioning component, so field numbering — and therefore the wire format — is identical. The same prov-config/prov-scan/ prov-ctrl endpoints carry the Wi-Fi or Thread message types depending on the build's network type (prov-scan does an otThreadDiscover sweep for Thread). sec2.proto is trimmed for scope but sec0/sec1 field numbers are unchanged. See proto/README.md for the endpoint ↔ message map and the nanopb .options conventions.

Repository layout

proto/        protobuf definitions (+ nanopb .options) — verbatim wire format
include/      public API (network_provisioning/network_prov_mgr.h)
src/          protocomm core, BLE + SoftAP transports, security 0/1, Wi-Fi handlers, manager
samples/      wifi_prov_ble and wifi_prov_softap — the reference applications
sim/          test-only fake Wi-Fi backend for headless simulation (native_sim/bsim)
tests/        native_sim ztest suites + a BabbleSim BLE end-to-end test (tests/bsim)
zephyr/       module.yml (consumable as a Zephyr module)
west.yml      standalone west manifest (pins the current stable Zephyr release)

Public API

#include <network_provisioning/network_prov_mgr.h>
#include <network_provisioning/scheme_ble.h>     /* or scheme_softap.h / scheme_console.h */

/* Pick the transport with a scheme object in the init config, e.g.
 * config.scheme = &network_prov_scheme_ble; (or _softap / _console).
 */
network_prov_mgr_init(config);                 /* load settings + credential store */
network_prov_mgr_is_provisioned(&provisioned); /* !wifi_credentials_is_empty()      */
/* BLE: service_key unused (NULL). SoftAP: service_key = AP password (or NULL
 * for an open AP).
 */
network_prov_mgr_start_provisioning(NETWORK_PROV_SECURITY_1, "abcd1234",
                                    "PROV_1234", NULL);
network_prov_mgr_wait();                        /* blocks until connected            */
network_prov_mgr_stop_provisioning();
network_prov_mgr_reset_wifi_provisioning();     /* explicit factory reset: erase creds */

Lifecycle events (NETWORK_PROV_START, CRED_RECV, CRED_FAIL, CRED_SUCCESS, END, …) are delivered to the callback registered in network_prov_mgr_config. Setting .wifi_conn_attempts in the config retries transient connect failures during provisioning before reporting failure — while retrying, status polls answer Connecting with the attempts remaining (WifiAttemptFailed), matching upstream's wifi_conn_attempts behavior. 0 keeps single-attempt semantics.

Additional upstream-parity manager APIs:

/* Advertise an app section in proto-ver (ver + extra capabilities). */
network_prov_mgr_set_app_info("myapp", "1.0", caps, ARRAY_SIZE(caps));

/* By default the service auto-stops a grace period after success
 * (CONFIG_NETWORK_PROV_AUTOSTOP_TIMEOUT_MS); opt out to manage teardown yourself. */
network_prov_mgr_disable_auto_stop(0);
network_prov_mgr_is_sm_idle();                  /* no session active */

/* Programmatic (headless) provisioning + post-failure / re-provision resets. */
network_prov_mgr_configure_wifi_sta("ssid", "passphrase");
network_prov_mgr_reset_wifi_sm_state_on_failure();
network_prov_mgr_reset_wifi_sm_state_for_reprovision();

/* Application-defined custom endpoints: create before start (so the transport
 * advertises them — a BLE characteristic / HTTP route / console endpoint),
 * register the handler after start (e.g. from the NETWORK_PROV_START event).
 * Reachable over all transports; up to CONFIG_NETWORK_PROV_MAX_CUSTOM_ENDPOINTS. */
network_prov_mgr_endpoint_create("custom-data");
network_prov_mgr_endpoint_register("custom-data", my_handler, my_ctx);
network_prov_mgr_endpoint_unregister("custom-data");

For the BLE transport, <network_provisioning/scheme_ble.h> adds network_prov_scheme_ble_set_service_uuid() and network_prov_scheme_ble_set_mfg_data() (call before start_provisioning) to override the 128-bit GATT service UUID and add manufacturer data to the scan response, e.g. for app-side device matching.

Console transport

With CONFIG_NETWORK_PROV_CONSOLE=y (which needs CONFIG_SHELL) and .scheme = &network_prov_scheme_console, the protocol is carried over the device console by a single shell command:

net_prov <endpoint> <session_id> <hex-request>

It decodes the hex request, dispatches it to the named protocomm endpoint and prints the response as lowercase hex. The session_id mirrors the per-session reset of the other transports — changing it opens a fresh protocomm session (resetting the security handshake), as a BLE reconnect or a new HTTP cookie does. service_name/service_key are unused for this scheme.

esp_prov's console transport is human-in-the-loop: drive it with

esp_prov.py --transport console --sec_ver 1 --pop abcd1234 \
            --ssid HomeNet --passphrase correct-horse-battery

and for each Client->Device msg : <endpoint> <session_id> <hex> line it prints, run net_prov <endpoint> <session_id> <hex> on the device console and paste the device's hex response back into esp_prov.

Quick start

# Standalone workspace
west init -m https://github.com/beriberikix/network-provisioning-zephyr wsp
cd wsp && west update

# Build & flash the sample (ESP32-S3 has native Wi-Fi + BLE coexistence)
west build -b esp32s3_devkitc/esp32s3/procpu \
    network-provisioning-zephyr/samples/wifi_prov_ble
west flash

Then open the ESP BLE Provisioning app, scan for PROV_ZEPHYR, enter the proof-of-possession abcd1234, pick your Wi-Fi network and submit. The device connects, persists the credentials, and reconnects automatically on the next boot.

See samples/wifi_prov_ble/README.rst for details, the esp_prov.py flow, and configuration knobs.

For SoftAP provisioning, build samples/wifi_prov_softap instead: the device hosts a PROV_ZEPHYR access point; join it with the phone and run the ESP SoftAP Provisioning app (or esp_prov.py --transport softap).

Running the tests

Unit tests for the protocol core (protocomm engine, security schemes 0/1 — including a full client-side security-1 handshake), an integration suite for the HTTP transport (a loopback HTTP client exercising URI routing and the cookie session semantics), an integration suite for the console transport (the full manager with the console scheme driven over the dummy shell backend — proto-ver, the sec1 handshake and an encrypted GetWifiStatus) and a unit test for the simulated Wi-Fi backend run on native_sim:

west twister -T network-provisioning-zephyr/tests -p native_sim --inline-logs

See tests/README.md for a per-suite breakdown and how to run each layer (native_sim, BabbleSim, esp_prov) individually.

A BabbleSim end-to-end test (tests/bsim/ble_e2e) exercises the BLE transport and the whole manager headlessly: a Zephyr "tester" central drives a full provisioning flow (sec1 handshake, scan, config, status) over a simulated radio against the device, which runs the real manager backed by a fake Wi-Fi driver (sim/wifi). Both a successful provisioning and a wrong-password failure injection are checked. With BabbleSim built (BSIM_OUT_PATH/BSIM_COMPONENTS_PATH set):

BOARD=nrf52_bsim/native network-provisioning-zephyr/tests/bsim/compile.sh
network-provisioning-zephyr/tests/bsim/ble_e2e/test_scripts/provision_success.sh
network-provisioning-zephyr/tests/bsim/ble_e2e/test_scripts/provision_wrong_password.sh

A second BabbleSim test (tests/bsim/thread_e2e) does the same for Thread over a simulated 802.15.4 radio: a node applies a dataset and attaches (forms its own network as leader), and a separate scenario has the device discover a peer node's network via otThreadDiscover.

An esp_prov SoftAP end-to-end test (tests/esp_prov) drives Espressif's real esp_prov client against a native_sim build over a host Ethernet TAP, asserting the success, wrong-password and unknown-SSID outcomes — verifying interoperability with the actual upstream tool, not just an in-tree client. See its README to run it locally.

CI runs all of the above — the native_sim suites, the BabbleSim BLE end-to-end test, the esp_prov SoftAP end-to-end test, and esp32s3_devkitc and esp32c3_devkitm builds of both samples — against the Zephyr release pinned in west.yml on every push and pull request; moving to a newer stable release is a one-line bump of that pin.

A separate multi-board build smoke test (.github/workflows/smoke.yml) compiles the samples across a representative spread of Wi-Fi-capable vendor stacks (Espressif, ST, NXP, Infineon, Silicon Labs; Xtensa/RISC-V/ARM). It runs on demand (workflow_dispatch) and when a v* release tag is pushed, and is informational — per-board results land in the run summary without blocking a release.

Using it as a module in an existing workspace

Add this repo to your west.yml and enable CONFIG_NETWORK_PROV_MGR=y plus at least one transport: CONFIG_NETWORK_PROV_BLE=y, CONFIG_NETWORK_PROV_SOFTAP=y and/or CONFIG_NETWORK_PROV_CONSOLE=y. The required Zephyr subsystems (WIFI, MBEDTLS, NANOPB, WIFI_CREDENTIALS, SETTINGS, and per transport BT_PERIPHERAL + a large ATT MTU, HTTP_SERVER + NET_DHCPV4_SERVER, or SHELL) are set up in the samples' prj.conf files — copy the relevant lines from wifi_prov_ble or wifi_prov_softap.

Important: CONFIG_BT_RX_STACK_SIZE=4096 (or larger) is required. The security-1 session setup and handshake run PSA crypto on the Bluetooth host RX thread via the GATT callbacks; Zephyr's default 1.2 kB RX stack silently overflows there and wedges the BLE controller as soon as a central connects.

Troubleshooting

Most field issues are subsystem sizing, not protocol bugs. The samples' prj.conf files carry the working values; the common symptoms:

A failed connection never erases stored credentials automatically; only an explicit network_prov_mgr_reset_wifi_provisioning() does.
